8
|
Bosch Climate 5000 Series Ducted Type (Medium & High Static) Air Conditioner / Heat Pump Installation Manual
05.2019 | Bosch Thermotechnology Corp.
Data subject to change
4 System Components
4.1 9K ~ 48K Models (Medium Static)
Figure 2
Air outlet
Air inlet
Air filter
Drain hose
Electric control cabinet
Refrigerant connecting pipe
Screw
Air filter
Illustrations in this manual are for explanatory purposes. The actual
shape of your indoor unit may be slightly diff erent. The actual shape
shall prevail.
