Installation Manual Bosch Climate 5000 Series Ducted Type (Medium & High Static) Air Conditioner / Heat Pump | 9
Bosch Thermotechnology Corp. | 05.2019
Data subject to change
4.2 60K Model (High Static)
Figure 3
Air outlet
Air inlet
Drain hose
Refrigerant connecting pipe
Electric control cabinet
Air filter
Heat exchanger
Illustrations in this manual are for explanatory purposes. The actual
shape of your indoor unit may be slightly diff erent. The actual shape
shall prevail.
