en Rails
30
1.
Turn the intermediate pane until the arrow is in
the top right.
2.
Insert the intermediate pane into the retainer at
the bottom and push it in firmly at the top.
3.
Push the left- and right-hand retainer downwards
until the intermediate pane is clamped ⁠.
4.
Attach the front pane downwards into the left- and
right-hand retainers ⁠ ⁠.
5.
Push the front pane to the appliance until the left-
and right-hand hook is opposite the support ⁠ ⁠.
6.
Push the front pane in at the bottom until you
hear it click into place.
7.
Open the appliance door slightly and remove the
tea towel.
8.
Screw both screws back in on the left and right of
the appliance door.
9.
Put the door cover in position and push down on it
until you hear it click into place.
10.
Close the appliance door.
Note:Do not use the cooking compartment again until
the door panes have been correctly fitted.
Rails
23 Rails
To thoroughly clean the rails and the cooking compart-
ment, or to replace the rails, you can remove the rails.
23.1 Detaching the rails
WARNING‒Risk of burns!
The shelf supports get very hot
▶ Never touch the shelf supports when hot.
▶ Always allow the appliance to cool down.
▶ Keep children at a safe distance.
1.
Lift the rail forwards and detach it ⁠.
2.
Swivel the entire rail outwards and unhook it at
the rear ⁠.
3.
Clean the rail.
23.2 Fitting the retainers
The retainers may fall out when you detach the rails.
