Familiarising yourself with your appliance en
9
Familiarising yourself with your appliance
4 Familiarising yourself with your appliance
4.1 Control panel
You can use the control panel to configure all functions
of your appliance and to obtain information about the
operating status.
On certain models, specific details such as colour and
shape may differ from those pictured.
1
2 2
1
Display with setting ring
You can use the digital setting ring to set the
appliance via the display.
You will see the current setting values, options
or relevant information.
→"Display", Page9
2
Buttons
You can use the buttons to directly set various
functions.
→"Buttons", Page9
4.2 Buttons
You can use the buttons to directly select various func-
tions.
Button Function
Switch the appliance on or off.
→"Basic operation", Page14
Select the microwave operating mode
directly.
→"Microwave", Page17
Open the "Operating modes" menu.
→"Operating modes", Page10
Select the favourites operating mode
directly.
→"Favourites", Page21
Go back one setting.
Start or pause operation.
→"Basic operation", Page14
Select the timer.
→"Setting the timer", Page16
Press and hold for approx. 4seconds
to activate the childproof lock.
→"Childproof lock", Page21
4.3 Display
The display is divided into different areas.
Digital setting ring
You can use the digital setting ring on the display to
change the setting values.
When you reach the minimum or maximum value avail-
able, this value remains on the display. If required, use
the setting ring to turn the value back again.
Finely tuned setting values
To fine-tune the setting values, e.g. to set a time to the
precise minute, press and hold the corresponding area
in the setting ring for around 1-2 seconds. The finely
tined setting values are shown in dots.
Status indicator
Status information is shown at the top of the display.
Symbol Meaning
Timer is activated.
→"Setting the timer", Page16
Childproof lock is activated.
→"Childproof lock", Page21
The appliance door is locked due to the
cleaning function or childproof lock.
→"Pyrolytic self-cleaning cleaning func-
tion", Page26
→"Basic settings", Page22
Wi-Fi signal strength for HomeConnect.
The more lines of the symbol are filled,
the better the signal.
If the symbol is struck through , there
is no Wi-Fi signal.
If there is an "x" at the symbol , there
is no connection to the HomeConnect
server.
→"HomeConnect ", Page23
Remote start with HomeConnect is ac-
tivated.
→"HomeConnect ", Page23
Remote diagnostics with HomeCon-
nect for maintenance is activated.
→"HomeConnect ", Page23
Settings area
The settings area is in the centre of the display.
You can see current options and settings that have
already been made in the settings area.
The menu and other setting options are arranged hori-
zontally. Selection lists for functions are vertically ar-
ranged. Swipe over the display to scroll in the settings
area. To select a function, press the function on the dis-
play.
→"Setting the operating mode", Page14
Possible symbols in the settings area
Symbol Meaning
Confirm the setting value.
