Bosch CS 200 - Commissioning the Freshwater System

6720850722 (2015/06) CS200
10 | Commissioning
Table 6 Settings in the Commissioning menu
5.3.2 Commissioning the freshwater system
Table 7 Settings in the Commissioning menu
Question Answer / setting
Is a solar pump with speed
control installed?
No | PWM | 0-10 V
Gross collector area 1
Question Answer / setting
How large is the gross
collector area?
0 to 500 m
2
Type collector array 1
Question Answer / setting
What type of collectors are
installed in the collector
array?
Flat-plate collector |
Vacuum tube collector
Gross collector area 2
Question Answer / setting
How large is the gross
collector area?
0 to 500 m
2
Type collector array 2
Question Answer / setting
What type of collectors are
installed in the collector
array?
Flat-plate collector |
Vacuum tube collector
Climate zone
Question Answer / setting
Which value corresponds to
the climate zone where the
solar system is installed?
Search the location of the
solar system in the climate
zone map ( Solar module
installation instructions)
and enter the value of the
climate zone.1...90...255
(90 is default figure)
Start solar thermal system
Question Answer / setting
Is the solar system filled and
vented? Do you want to
start the solar system now?
Yes | No
Menu item
Start configuration wizard?
Menu item
Question Answer / setting
Check before starting the configuration wizard:
• Module installed and address set?
• Temperature sensor installed?
• System charged and vented?
Start the configuration
wizard?
Yes | No
Operating mode
Question Answer / setting
Which system is installed?
Is the coding switch
correspondingly set at the
module?
Solar | DHW (Freshwater) |
Transfer system
Size of freshwater station
Question Answer / setting
What is the size of the
installed freshwater
station?
15 (22) | 27 | 40 l/min
Freshwater station 2...4
Question Answer / setting
Are freshwater extension
stations installed?
Yes | No
Change freshwater configuration
Question Answer / setting
Is the freshwater system
correctly configured with all
functions and additional
functions?
Graphic configuration of the
freshwater system
Max. DHW temp.
Question Answer / setting
What is the maximum
temperature of the DHW?
60 ... 80 °C
DHW temp.
Question Answer / setting
At what temperature should
the DHW be maintained?
10 ... 60 (80) °C
Circulation time
Question Answer / setting
Should the DHW circulation
run time-controlled?
Yes | No
Circulation pulse
Question Answer / setting
Should the DHW circulation
run at every DHW draw?
Yes | No
Menu item
