en Steam
18
2.
Use the control ring to change the cooking time.
a The change is applied immediately.
11.3 Steam assistance
When you cook with steam assistance, the appliance
introduces steam into the cooking compartment at vari-
ous intervals. This gives your food a crispy crust and a
shiny surface. Meat stays juicy, tender and only under-
goes a minimum reduction in volume.
Suitable types of heating with steam-assisted
cooking
Only certain types of heating are suitable for operation
with steam-assisted cooking.
You can switch on steam assistance for the following
types of heating:
¡ 4D hot air
¡ Top/bottom heating
¡ Circulated air grilling
¡ Keeping warm
Setting steam-assisted cooking
Requirement:The water tank has been filled.
→"Filling the water tank", Page16
1.
Select the "Types of heating" operating mode.
2.
Press a suitable type of heating.
a The temperature is highlighted in white.
3.
Use the control ring to set the temperature.
4.
Press "Added steam".
5.
Use the control ring to set the steam setting.
Steam setting Added steam
0 None
01 Low
02 Medium
03 High
6.
Press to start.
Note:If the water tank runs dry during operation, a
notification appears in the display. The appliance
continues to operate without added steam.
→"Filling the water tank", Page16
a The appliance begins to heat up.
a The time, how long the appliance has already been
in operation, and the settings are shown in the dis-
play.
7.
When the food is ready, press to switch the appli-
ance off.
8.
Empty the water tank and dry the cooking compart-
ment.
→"After every steam operation", Page18
Changing the steam setting
You can change the steam setting at any time.
1.
Press "Added steam".
2.
Use the control ring to change the steam setting.
a The change is applied immediately.
Changing the temperature
Once operation has started, you can change the tem-
perature directly.
▶
Use the control ring to change the temperature.
a The temperature is applied immediately.
Changing the type of heating
When you change the type of heating, the other set-
tings will also be reset.
1.
Press to pause operation.
2.
Press "Types of heating".
3.
Press the type of heating that you want to use.
a The corresponding default temperature appears in
the display.
11.4 After every steam operation
The remaining water is pumped back into the water
tank after every operation with steam. Then empty and
dry the water tank and the cooking compartment.
Emptying the water tank
WARNING‒Risk of burns!
The water tank may heat up while the appliance is in
operation.
▶ Wait until the water tank has cooled down from the
previous operation.
▶ Remove the water tank from the tank recess.
ATTENTION!
Drying the water tank in the hot cooking compartment
leads to damage to the water tank.
▶ Do not dry the water tank in the hot cooking com-
partment.
Cleaning the water tank in the dishwasher will damage
it.
▶ Do not clean the water tank in the dishwasher.
▶ Clean the water tank with a soft cloth and standard
washing-up liquid.
1.
Use to open the control panel.
2.
Remove the water tank.
3.
Carefully remove the lid of the water tank.
4.
Empty the water tank, clean it with detergent and
then rinse it thoroughly with clean water.
5.
Dry all parts with a soft cloth.
6.
Rub the seal on the lid until dry.
7.
Leave the water tank to dry with the lid open.
8.
Place the lid on the water tank and push down on it.
9.
Insert the water tank and close the control panel.
Drying the condensation tray
WARNING‒Risk of burns!
The appliance becomes hot during operation.
▶ Allow the appliance to cool down before cleaning.
Requirement:The cooking compartment has cooled
down.
1.
Open the appliance door.
2.
Note:
The condensation tray is underneath the cooking
compartment.
