-8-
:3(9.43&1*8(7.59.43&3)5*(.+.(&9.438
.8(433*(9 9-* 51:, +742 9-* 54<*7 84:7(* '*+47* 2&0.3, &3>
&88*2'1>&)/:892*39847(-&3,.3,&((*8847.*8. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
.7(:1&7&<8
 For tool specifications refer to the nameplate on your tool.
&=.2:2&5&(.9.*8
Blade 7-1/4"
Blade arbor hole Diamond
Depth of cut at 90° 2-3/8"
Depth of cut at 45° 1-29/32"
Depth of cut at 53° 1-5/8"
1/4
1/2
3/4
1X
OOD
MBER
TRIGGER SWITCH
AUXILIARY HANDLE
MAIN HANDLE
DEPTH
ADJUSTMENT
LEVER
FOOT
LOWER GUARD
LOWER GUARD
LIFT LEVER
CALIBRATED DEPTH BRACKET
Calibrated For Standard Lumber Sizes
BLADE WRENCH
& STORAGE AREA
SAW HOOK
To use, lift up hook until it
snaps into the open
position.
When not in use, always
lower hook until it snaps
into the closed position.
CALIBRATED
BEVEL
QUADRANT
UPPER GUARD
45° STOP SPRING
BEVEL
ADJUSTMENT
LEVER
BLADE STUD
OUTER WASHER
LOCK BUTTON
FIG. 1
FIG. 1A
DEPTH OF
CUT MARKS
CONTOUR
OF LEVER
OIL PLUG
PIVOT STUD
AUXILIARY HANDLE
BRUSH
CAP
BEVEL INDICATOR
