Bosch CM8S - User Manual

Questions and Answers

B
Brittany AtkinsAug 17, 2025
Why Bosch CM8S motor does not start?
- D
  Dominic JonesAug 18, 2025
  The Bosch Saw motor might not start due to several reasons. First, ensure the unit is properly plugged into a functioning outlet, or try a different outlet. It's also possible that the power source fuse or time delay fuse has blown, requiring a 15-Amp time delay fuse or circuit breaker replacement. Another potential cause is worn brushes, which may need replacement as described in the Maintenance and Lubrication section. If none of these solutions work, it may require authorized service.
X
xmortonAug 20, 2025
What to do if Bosch Saw blade binds, jams, burns wood, or makes rough cuts?
- M
  matthewcummingsAug 20, 2025
  If the Bosch Saw blade binds, jams, burns wood, or makes rough cuts, consider the following: Ensure you are operating the saw correctly, as detailed in the Saw Operations section. A dull blade can cause these issues, so replace or sharpen it. Using the wrong blade can also lead to problems; replace it with an 8-1/2” diameter blade designed for the material you're cutting. Finally, a bent blade will cause these issues, so replace the blade.
H
Haley HessAug 23, 2025
Why does Bosch CM8S vibrate or shake?
- B
  Brandon MooreAug 23, 2025
  The Bosch Saw may vibrate or shake due to several reasons. The saw blade might not be round, or it could be damaged or loose. Try replacing the blade. Also, check that the blade is properly seated on the inner washer, referring to the instructions on Removing and Installing Blades. If the issue persists, it may require authorized service.
T
triciajonesAug 26, 2025
What to do if Bosch Saw cannot rotate table to change miter angle?
- E
  Eric RussellAug 26, 2025
  If you cannot rotate the table to change the miter angle on your Bosch Saw, there are a few possible reasons. First, the miter lock knob may be tightened; turn it counterclockwise to loosen it. Second, the miter detent lever may be engaged with a detent (slot) in the detent plate; pull up on the miter detent lever to disengage it from the detent slot. Finally, sawdust accumulation can obstruct movement; vacuum or blow out dust around the turntable, wearing eye protection.
J
Jennifer ChristensenAug 28, 2025
Why Bosch Saw head assembly does not slide freely when attempting a slide cut?
- A
  Alyssa JonesAug 28, 2025
  If the Bosch Saw head assembly does not slide freely when attempting a slide cut, it is likely that the slide rail lock knob is engaged. Rotate the slide rail lock knob counter clockwise to disengage it.
J
Jessica GonzalesAug 30, 2025
What to do if Bosch Saw head assembly slides forward and back when making a chop cut?
- L
  Logan PadillaAug 30, 2025
  If the Bosch Saw head assembly slides forward and back when making a chop cut, the slide rail lock knob is likely disengaged. Rotate the slide rail lock knob clockwise to lock the head in place.
B
Brandy BarreraSep 1, 2025
What to do if Bosch CM8S blade does not cut completely through workpiece?
- M
  Miguel JamesSep 2, 2025
  If the Bosch Saw blade does not cut completely through the workpiece, it could be because the depth stop plate is pulled out for non-through cuts. Push the depth stop plate inward to set it for full-depth cuts. Another reason could be that the replacement blade is less than 8-1/2” diameter; change to a blade that is fully 8-1/2” diameter.
K
Kimberly JonesSep 4, 2025
Why Bosch CM8S Saw head assembly will not fully raise or blade guard will not fully close?
- M
  Michael SolisSep 4, 2025
  If the Bosch Saw head assembly will not fully raise or the blade guard will not fully close, several factors could be the cause. First, check if the head assembly lock pin is engaged and pull it out to allow the head assembly to go up. Sawdust accumulation can also obstruct movement; clean the head assembly. If neither of these solutions works, authorized service may be required.
B
bryanpattersonSep 7, 2025
What to do if Bosch CM8S blade hits table?
- C
  Carolyn HarrisSep 7, 2025
  If the Bosch Saw blade hits the table, it indicates a misalignment that requires authorized service.
N
Nicholas SmithSep 9, 2025
Why Bosch Saw head assembly does not bevel to desired position?
- J
  josephjacksonSep 9, 2025
  If the Bosch Saw head assembly does not bevel to the desired position, the bevel lock is likely engaged. Pull the bevel lock forward to unlock the head assembly.

Summary

Safety Symbols and Warnings

General Power Tool Safety

Essential safety guidelines for operating power tools to prevent accidents and injury.

Miter Saw Specific Safety

Crucial safety practices and precautions for using miter saws safely.

Additional Safety Rules

Getting To Know Your Miter Saw

Adjustments and Calibration

Setting Blade Depth

Miter and Bevel Stop Calibration

Steps to calibrate miter detents, bevel stops, and scale pointers.

Transporting and Mounting

Transporting the Saw

Placement and Mounting

Instructions for attaching the saw to a workbench or stand.

Preparing for Saw Operations

Switch Activation and Safety

How to safely activate the saw's switch and use of padlock.

Body and Hand Positioning

Guidelines for correct posture and hand placement to avoid injury.

Workpiece Support and Fences

Miter Saw Operations

Miter Detent System Usage

Cut Types: Chop, Slide, Miter, Bevel

Specialized Cuts: Grooves and Molding

Maintenance, Lubrication, and Troubleshooting

Maintenance Procedures

Troubleshooting Common Issues

Bosch CM8S Specifications

General

Voltage	120 V
No Load Speed	5, 600 RPM
Arbor Size	5/8 inches
Saw Blade Bore	5/8 inches
Weight	37 lbs
Cutting Depth at 90°	2-1/2 inches
Type	Miter Saw
Blade Diameter	8.5 inches
Bevel Angle Range	45° Left
Cutting Depth at 45°	2 inches
Miter Angle Range	0 - 52 degrees
