6720816118 (2015/08) Bosch Control
10 | Specifications
6 Specifications
7 Maintenance and troubleshooting
7.1 Cleaning the touch screen
▶ Swipe from left to right to lock the touch screen.
The screen is now locked and the installed software version
is displayed on the screen.
Fig. 18 Touch screen protection
▶ Clean the touch screen within 15 seconds with a clean, dry
cloth.
7.2 Change Wi-Fi network or new network
password
To connect the Bosch Control to a new Wi-Fi network or if the
existing network has a new password:
▶ Reset the Bosch Control ( section 7.3.2).
▶ Follow the step to set a Wi-Fi network ( section 4.6.3).
7.3 Troubleshooting
7.3.1 After a power outage
All settings are saved during a power outage. After the
connection is re-established with the Wi-Fi network, the
settings will be synchronised with the external server.
▶ Check the date and time setting.
If a connection cannot be made with the internet, the date and
time settings can be applied through the local Wi-Fi network
with the App from a smart device. Date and time are
automatically synchronised.
7.3.2 Reset Bosch Control
If the Bosch Control no longer works properly, it can be discon-
nected briefly from the wall plate and then re-attached
( fig. 7, page 6).
If this does not solve the problem, with the Bosch Control
mounted on the wall, the reset key ( fig. 19) can be pressed
for a few seconds to remove the fault. If the fault occurs again,
then contact your installer or the Bosch Thermotechnology
Corp. Technical Support team.
Fig. 19 Reset
Description Unit Value
Voltage supply V DC 14.3 to 16.0
Consumption (maximum) W 0.9
Dimensions (L x W x H) inch
mm
4 x 6.7 x 1
100 x 145 x 27
Weight lbs
g
0.55
250
Permissible operating temp. °F
°C
32 to 113
0 to 45
Permissible relative humidity % 10 to 90
Connection (Wi-Fi) 802.11 b/g
Table 3 Specifications
