D1255RB/D1256RB/D1257RB
|
Installation
Guide | 4.0 D1256RB Programming Requirements
.
Bosch Security Systems B.V. | 2020.03 | F01U011791-03 11
4.2.2 B9512G/B8512G and D9412GV4/D7412GV4/D7212GV4 v2.xx
RPS Menu Location
Bx512G Program Record Sheet > Area Wide Parameters > Area/Bell Parameters, Open Close
Options > Area Arming Text
Figure 15: Example – Area Arming Text for Fire Applications
Area Arming Text
Area Name Text
Account Is On Text
Area # Is On Text
Area # Is Not Ready Text
Area # Is Off Text
Area “#”
**Fire System** **Fire System** **Fire System** **Fire System** **Fire System**
Area Name Text − ** FIRE SYSTEM **
Sets what text is displayed at the keypad. Information purposes only
Account Is On Text − ** FIRE SYSTEM **
Text to display at the keypad for each area. Program this parameter as *Fire System*.
Area # Is On Text − ** FIRE SYSTEM **
Text to display at the keypad for each area. Program this parameter as *Fire System*.
Area # Is Not Ready Text − ** FIRE SYSTEM **
Text to display at the keypad for each area. Program this parameter as *Fire System*.
Area # Is Off Text − ** FIRE SYSTEM **
Text to display at the keypad for each area. Program this parameter as *Fire System*.
4.3 Custom Functions
The Custom Functions section does not apply to the B9512G/B8512G or
D9412GV4/D7412GV4 v2.xx. Selecting the corresponding Keypad Type in RPS
automatically selects the keypad and functions. Refer to the appropriate program entry
guide for specific control panel information. For the B9512G/B8512G and
D9412GV4/D7412GV4 v2.xx control panels, proceed to section 4.4.1.
Figure 16: Example – Custom Functions Recommended for UL864 9
th
Edition
Custom Function Text
Custom Function Keyst r okes
CF 128
A L A R M S I L E N C E ?
1 2 5 6 0 0 E _ _ _ _ _ _ _ _ _
CF 129
T R O U B L E S I L E N C E ?
A 4 C C _ _ _ _ _ _ _ _ _ _ _ _
CF 130
D E T E C T O R R E S E T ?
A 4 7 _ _ _ _ _ _ _ _ _ _ _ _ _
CF 131
A N U N C I A T O R R E S E T
1 2 5 6 0 0 C A 4 7 _ _ _ _ _ _
In Figure 16, C = [ESC], E = [ENT], A = [Command].
In the D1256RB, Custom Functions must be programmed as indicated in Figure 15. Refer to Keypad
(Command Center), Custom Functions in the program record sheet for your control panel for
information on making the function keys operational.
The passcode 125600 is used in the following examples. You can use any passcode.
CF 128 − ALARM SILENCE ?
Keystrokes: [1] [2] [5] [6] [0] [0] [ENT]. Program this custom function as the first Menu item in the
D1256RB display. The Alarm Silence function is executed when the [ALARM SILENCE] key is
pressed on the D1256RB. The control panel sees the keystroke entry as a valid passcode having the
authority to silence a ringing fire bell in the area. The [ENT] key has the enter function.
