Bosch DiBos - Live mode; The user interface in live mode

DiBos Operating Manual 5
Live mode
Bosch Security Systems A1/2005-09 F.01U.512.560
Live mode
The user interface in live mode
The user interface is divided into different areas.
1
Menu bar with current date and time
2
Display bar
3
Device list with camera and remote stations
4
Image area with image window
5
Control and status field
6
Event field
