Bosch DIVAR 2000 Installation Manual

Table of contents
1
Safety 4
1.1 Important safety instructions 4
1.2 FCC and UL 6
2
Short information 6
3
System overview 7
4
Planning information 7
4.1 Unpacking 7
4.2 Package contents 7
5
Installation 8
5.1 Make connections 8
5.1.1 Back panel connectors DIVAR network 2000/3000 (no PoE) 9
5.1.2 Back panel connectors DIVAR network 2000 (8 PoE) 10
5.1.3 Back panel connectors DIVAR network 2000/3000 (16 PoE) 11
5.1.4 Back panel connectors DIVAR network 5000 (no PoE) 12
5.1.5 Back panel connectors DIVAR network 5000 (16 PoE) 13
5.1.6 Back panel connectors DIVAR hybrid 3000 14
5.1.7 Back panel connectors DIVAR hybrid 5000 15
5.1.8 Browser setup 15
5.2 Powering up 16
5.3 Startup wizard 16
5.4 Login 17
5.5 Logout/Shutdown 17
6
First time operation 17
6.1 Live viewing mode 17
6.2 Quick menu 18
6.3 Main menu 19
7
Maintenance 19
7.1 Insert DIVAR 5000 in rack 19
7.2 Replace internal battery 20
7.3 Install HDD 20
7.4 Install DVD 20
8
Decommissioning 20
8.1 Transfer 20
8.2 Disposal 20
DIVAR 2000 / DIVAR 3000 / DIVAR
5000
Table of Contents | en 3
Bosch Security Systems Installation Manual 2016.08 | v1.0 | AM18-Q0712

Bosch DIVAR 2000 Specifications

General

Number of fans	1 fan(s)
Input bandwidth	256 Mbit/s
Number of users	128 user(s)
Recording modes	Manual, Schedule, Stop
Output bandwidth	128 Mbit/s
Maximum resolution	3840 x 2160 pixels
Video input channels	16 channels
Supported resolutions	3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Video recording modes	720p, 1080p
Video motion detection	Yes
Video formats supported	H.264, H.265, M-JPEG
DC-in jack	No
Disc types supported	DVD, DVD+R, DVD+RW
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
Supported network protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS/DDNS, IP Filter, PPPoE, FTP
Power over Ethernet (PoE) ports quantity	8
HDD capacity	2000 GB
HDD interface	Serial ATA III
Maximum storage capacity	6 TB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Total Power over Ethernet (PoE) budget	115 W
Power over Ethernet (PoE) power per port	25.5 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 93 %
Mobile operating systems supported	Android, iOS
Sustainability certificates	RoHS
Certification	FCC, UL, CE,
Product color	Black

Weight and Dimensions

Depth	323 mm
Width	375 mm
Height	53 mm
