36 en | OSS licenses DIVAR IP 7000 (2U)
2016.07 | V2 | DOC Installation Manual Bosch Sicherheitssysteme GmbH
apply to such Executable Files and/or Source Code. You may not offer or
impose any terms on the Work that alter or restrict the terms of this
License or the recipients' exercise of the rights granted hereunder. You
may not sublicense the Work. You must keep intact all notices that refer to
this License and to the disclaimer of warranties. You may not distribute
the Executable Files or Source Code with any technological measures that
control access or use of the Work in a manner inconsistent with the terms
of this License.
You agree not to use the Work for illegal, immoral or improper
purposes, or on pages containing illegal, immoral or improper material. The
Work is subject to applicable export laws. You agree to comply with all
such laws and regulations that may apply to the Work after Your receipt of
the Work.
Representations, Warranties and Disclaimer. THIS WORK IS PROVIDED "AS
IS", "WHERE IS" AND "AS AVAILABLE", WITHOUT ANY EXPRESS OR IMPLIED
WARRANTIES OR CONDITIONS OR GUARANTEES. YOU, THE USER, ASSUME ALL RISK IN
ITS USE, INCLUDING COPYRIGHT INFRINGEMENT, PATENT INFRINGEMENT,
SUITABILITY, ETC. AUTHOR EXPRESSLY DISCLAIMS ALL EXPRESS, IMPLIED OR
STATUTORY WARRANTIES OR CONDITIONS, INCLUDING WITHOUT LIMITATION,
WARRANTIES OR CONDITIONS OF MERCHANTABILITY, MERCHANTABLE QUALITY OR
FITNESS FOR A PARTICULAR PURPOSE, OR ANY WARRANTY OF TITLE OR NON-
INFRINGEMENT, OR THAT THE WORK (OR ANY PORTION THEREOF) IS CORRECT, USEFUL,
BUG-FREE OR FREE OF VIRUSES. YOU MUST PASS THIS DISCLAIMER ON WHENEVER YOU
DISTRIBUTE THE WORK OR DERIVATIVE WORKS.
Indemnity. You agree to defend, indemnify and hold harmless the Author
and the Publisher from and against any claims, suits, losses, damages,
liabilities, costs, and expenses (including reasonable legal or attorneys’
fees) resulting from or relating to any use of the Work by You.
Limitation on Liability. EXCEPT TO THE EXTENT REQUIRED BY APPLICABLE
LAW, IN NO EVENT WILL THE AUTHOR OR THE PUBLISHER BE LIABLE TO YOU ON ANY
LEGAL THEORY FOR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL, PUNITIVE OR
EXEMPLARY DAMAGES ARISING OUT OF THIS LICENSE OR THE USE OF THE WORK OR
OTHERWISE, EVEN IF THE AUTHOR OR THE PUBLISHER HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
Termination.
This License and the rights granted hereunder will terminate
automatically upon any breach by You of any term of this License.
Individuals or entities who have received Derivative Works from You under
this License, however, will not have their licenses terminated provided
such individuals or entities remain in full compliance with those licenses.
Sections 1, 2, 6, 7, 8, 9, 10 and 11 will survive any termination of this
License.
If You bring a copyright, trademark, patent or any other infringement
claim against any contributor over infringements You claim are made by the
Work, your License from such contributor to the Work ends automatically.
Subject to the above terms and conditions, this License is perpetual
(for the duration of the applicable copyright in the Work). Notwithstanding
the above, the Author reserves the right to release the Work under
different license terms or to stop distributing the Work at any time;

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Bosch DIVAR IP 7000 and is the answer not in the manual?

Bosch DIVAR IP 7000 Specifications

General IconGeneral
Microphone inYes
USB 2.0 ports quantity4
Ethernet LAN (RJ-45) ports3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
Wi-FiNo
Ethernet LAN data rates10, 100, 1000 Mbit/s
RAID levels5, 6
Storage drive size3.5 \
Storage drive capacity120 GB
Storage drive interface-
Installed storage drive typeSSD
Supported storage drive typesHDD & SSD
Total installed storage capacity0.24 TB
Number of storage drives supported10
Bus typeQPI
SteppingC0
Scalability1S
Processor codeSR14S
Processor cache8 MB
Processor modelE3-1275V3
System bus rate- GT/s
Processor seriesIntel Xeon E3-1200 v3
Processor socketLGA 1150 (Socket H3)
Processor threads8
Processor codenameHaswell
Processor frequency3.5 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor package size37.5 x 37.5 mm
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency3.9 GHz
Processor operating modes64-bit
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)84 W
On-board graphics card modelIntel® HD Graphics P4600
Memory bandwidth supported by processor (max)25.6 GB/s
Maximum internal memory supported by processor32 GB
Internal memory8 GB
Memory clock speed1666 MHz
Internal memory typeDDR3
Thermal solution specificationPCG 2013D
Maximum number of PCI Express lanes16
Memory types supported by processorDDR3-SDRAM
Memory channels supported by processorDual
Intel Identity Protection Technology version1.00
Chassis typeRack (2U)
Cooling typeActive
Product colorBlack
Number of fans2 fan(s)
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power supply unit (PSU) capacity740 W
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)8 - 90 %
TypeStorage server
Optical drive typeDVD-RW
Operating system installedWindows Storage Server 2012 R2
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1250 MHz
CertificationCE, UL
Processor ARK ID75464
Weight and Dimensions IconWeight and Dimensions
Depth648 mm
Width437 mm
Height89 mm
Weight23600 g
