DS484Q/DS486Q | Installation Instructions | 8.0 Specifications
.
Bosch Security Systems, Inc. | 7/05 | 4998138530F 19
8.0 Specifications
Table 11: DS484Q and DS486Q Specifications
Alarm Form C 0.2 A @ 30 VDC
Output Period: 3 sec
EDC NC 0.2 A @ 30 VDC
Output Period: 3 sec
Alarm Output
Tamper NC 0.1 A @ 30 VDC
Output Period: While the cover is removed
Beam Interrupt Time Adjustable from 50 ms to 500 ms
Selectable Beams Two Groups by four Channels
Environmental Discrimination Circuit Output Normally-closed contacts rated at 0.2 A @ 30
VDC
DS484Q 120 m (400 ft) Outdoor
DS486Q 200 m (660 ft)
DS484Q 240 m (800 ft)
Maximum Coverage
Indoor
DS486Q 300 m (1000 ft)
Enclosure Design
Material Polycarbonate
Dimensions (HxWxD) 35 cm x 10 cm x 11 cm
(13.75 in. x 4 in. x 4.1 in.)
Receiver 1.2 kg (2.64 lb) Total Weight
Transmitter 1.2 kg (2.64 lb)
Environmental Considerations
Operating Temperature
-25° C to + 55° C
(-13°F to + 130° F)
IP Rating IP 54 (protection against dust; protection against
splashing water)
Mounting
Location Surface or pole mount
Pattern Pointability
±90° horizontal, ±10° vertical
Power Requirements
Voltage 10.5 VDC to 28 VDC non-polarized
Receiver 80 mA standby, 50 mA alarm
DS484Q 35 mA
Current Draw
Transmitter
DS486Q 55 mA
Backup Power Requirements 4 hours (120 mAh) minimum required for
UL Certificated Installations
Temper Output Normally-closed contacts rated at 0.1 A @ 30 VDC
Trigger Response Time Selectable response time of 35 ms to 700 ms
