DS7400XiV4-EXP | User Guide | 6.0 Day to Day Operations EN | 9
Bosch Security Systems | 6/05 | 4998154961B
6.1.3 Perimeter Arming
Perimeter arming is used when someone is still in the building, only the exterior (perimeter) zones must be armed,
and an entry/exit delay is in effect.
The green Status LED must be lit and, if using a text keypad, “Ready to Arm” must be displayed. If the green
LED is not on or the keypad displays “Not Ready,” you must use other methods to arm the system (refer to Section
6.2.2 Force Arming on page 13 or Section 6.2.3 Zone Bypass on page 14).
Table 5: Perimeter Arming
Equipment Command Sequence What Happens What To Do
Text Keypad LED
Keypad
[PIN]
[Perimeter Only]
• The red Armed LED flashes.
• “Perimeter On” is displayed. *
• “Exit Now” is displayed during exit-delay.
*
• The green Status LED lights steady.
• A single beep sounds.
• The red Armed LED lights steady when
the exit-delay period ends.
• The yellow Perimeter LED lights steady.
**
• Only exterior protection zones are
armed.
• Move freely around the
interior.
• Opening any exterior door
or window triggers an
alarm.
RF3341 Keypad [PIN][#][3] • The LED flashes indicating a signal was
sent to your security system.
• Only exterior protection zones are
armed.
• Move freely around the
interior.
• Opening any exterior door
or window triggers an
alarm.
RF3332/RF3332E,
RF3334/RF3334E
Not applicable
* Text Keypad only
** LED Keypad only
