RAID Subsystem DVA-12T | Installation Manual Specifications | en 43
Bosch Security Systems F.01U.027.798 | V1 | 2006.06
7 Specifications
7.1 Technical Specifications
Environmental Specifications
Humidity 5 to 95% (non condensing – operating and non-operating)
Temperature Operating: 0º to 40ºC
Non-operating: -40º to 60ºC
Altitude Sea level to 12,000ft
Power Requirements
Input Voltage 115VAC @ 6A
240VAC @ 3A with PFC
(auto-switching)
Frequency 47-63Hz
Power Consumption 1197 BTU/hour (350W)
Dimensions w/o front handles w/ front handles
Height 88mm 88mm
Width 446mm 482mm
Length 490mm 505mm
Package dimensions 344H x 600W x 670D mm
System Weight
Net weight: 23.5kg
Gross weight: 25.0kg (without drives)
EMI/EMC
• FCC Class-B
• CE
Safety Requirements
• UL
• CB
Shock
Half-sine Operating: 10G peak, 11ms duration
Non-operating: 100G, 180 in/sec 240G, 2ms, half-sine
Square 240G, 2ms, half-sine
Vibration
Operating 5 to 500Hz, 0.2G, X/Y/Z
Non-operating 5 to 500Hz, 1.0G, X/Y/Z
