Bosch EMS 2 - English; Explanation of Symbols; Explanation of Symbols and Safety Instructions

9
Table of contents
MP 100 – 6721819201 (2020/02)
Table of contents 1 Explanation of symbols and safety
instructions
1.1 Explanation of symbols
Warnings
In warnings, signal words at the beginning of a warning are used
to indicate the type and seriousness of the ensuing risk if
measures for minimising danger are not taken.
The following signal words are defined and can be used in this
document:
DANGER:
DANGER indicates that severe or life-threatening personal
injury will occur.
WARNING:
WARNING indicates that severe to life-threatening personal
injury may occur.
CAUTION:
CAUTION indicates that minor to medium personal injury may
occur.
NOTICE:
NOTICE indicates that material damage may occur.
Important information
The info symbol indicates important information where there is
no risk to people or property.
Additional symbols
Table 5
1 Explanation of symbols and safety instructions . . . . . .9
1.1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . .9
1.2 General safety instructions . . . . . . . . . . . . . . . . . . 10
2 About the product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.2 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.3 Cleaning and care. . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.4 Additional accessories. . . . . . . . . . . . . . . . . . . . . . 12
3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.1 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2 Electrical connection. . . . . . . . . . . . . . . . . . . . . . . 12
3.2.1 Establishing the BUS connection and
temperature sensor (extra-low voltage side) . . . . 12
3.2.2 Connecting the power supply, pump and
mixer (mains voltage side) . . . . . . . . . . . . . . . . . . 13
3.2.3 Connection diagrams with system
schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4 Commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5 Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6 Environmental protection and disposal . . . . . . . . . . . 15
Symbol Meaning
▶ a step in an action sequence
 a reference to a related part in the document
• a list entry
– a list entry (second level)
