Conventional Automatic Fire Detectors Table of contents | en 3
Bosch Sicherheitssysteme GmbH
User manual
2021.03 | 11 | F.01U.004.377
Table of contents
1
Product Description 5
2
System Overview 6
2.1 Configuration of the Detector 6
2.2 Functional Description of Sensor Technology 6
2.2.1 Optical Sensor (Smoke Detector) 6
2.2.2 Thermal Sensor (Heat Detector) 6
2.2.3 Chemical Sensor (Gas Sensor) 6
2.3 System Description 6
2.4 Features 7
3
Planning 8
3.1 Basic Planning Guidelines 8
3.2 Use in Fire Barriers Conforming to DIBt 8
4
Installation 9
4.1 Overview of Detector Bases 9
4.2 Overview of Detector Base Sounder 10
4.3 Mounting the Bases 10
4.4 Wiring 11
4.4.1 Wiring MS 400/MS 400 B 12
4.4.2 Wiring MSR 320 13
4.4.3 Wiring MSS 300 14
4.5 Installing the Detector Head 14
4.6 Detector Removal 15
5
Accessories 16
5.1 EOL Module for Line Termination According to EN 54-13 16
5.2 Support Plates for Detector Identification 16
5.3 SK 400 Protective Basket 16
5.4 SSK 400 Protective Dust Cover 17
5.5 WA400 Detector Console 17
5.6 MH 400 Detector Heating Element 17
5.7 Remote Indicators 17
6
Order Overview 22
6.1 Detector Variants 22
6.1.1 Detectors with 820 Ohm Alarm Resistor 22
6.1.2 Detectors with 470 Ohm Alarm Resistor* 22
6.2 Detector Bases 22
6.3 Detector Accessories 22
6.4 Installation Accessories 23
6.5 Detector Base Sounders 23
6.6 Remote Indicators 23
6.7 Service Accessories 23
7
Maintenance and Service 25
7.1 Coding of the Detector Types 26
7.2 Test Procedure for Detectors with C-Sensor 26
7.3 Test Procedure for Detectors without C-Sensor 27
7.4 Warranty 27
7.5 Repair 27
7.6 Disposal 27
7.7 Additional Documentation 27
