Bosch FCP‑320 Series User Manual

8 en | Planning Conventional Automatic Fire Detectors
2021.03 | 11 | F.01U.004.377
User manual
Bosch Sicherheitssysteme GmbH
3 Planning
i
Notice!
FCP-320/FCH-320 Conventional Automatic Fire Detectors are not designed for exterior use.
3.1 Basic Planning Guidelines
– The planning of multisensor fire detectors takes place according to the guidelines for
optical detectors, until an independent guideline has been worked out with the VdS (see
DIN VDE0833 Part2 and VDS2095):
– Maximum monitoring area 120m
2
– Maximum installation height 16m.
– Maximum permitted air speed: 20m/s.
– A maximum of 32 detectors can be connected per primary line. This number is limited to
20detectors when connected to an UGM2020 (GIF/GIF2).
3.2 Use in Fire Barriers Conforming to DIBt
The FCH‑T320‑FSA and FCP-O320 are available for use in fire barriers conforming to the
guideline of the DIBt (Deutsches Institut für Bautechnik/German Institute for Building
Technology).
When planning for fire barriers conforming to DIBt, the FCH-T320‑FSA detector has already
been set to class A1R.
Both models have DIBt approval.
