MUX expansion module Mounting | en 13
Bosch Security Systems. Inc. 2016.10 | 1.0 | F.01U.330.684
3 Mounting
Danger!
Make sure all power is removed before making any electrical
connections. Failure to do so may result in personal injury and/
or damage to equipment.
Caution!
Static-sensitive components!
The FACP and modules contain static‑sensitive components and
must be handled with care. Follow proper antistatic handling
procedures.
FPE-7039 board mounting
Figure3.1: Mounting the FPE-7039
1 FPE-7039 2 FACP
3 Mounting holes (4) for
plastic standoffs
4 FACP connector pins
(align with FPE-7039)
5 Mounting screw 6 Ground wire
