English
Safety Notes
Working safely with the measuring tool is
possible only when the operating and safe-
ty information are read completely and the
instructions contained therein are strictly
followed. Never make warning labels on
the measuring tool unrecognisable. SAVE
THESE INSTRUCTIONS.
Caution – The use of other operating or adjusting
equipment or the application of other processing meth-
ods than those mentioned here, can lead to dangerous
radiation exposure.
The measuring tool is provided with a warning label
(marked with number 15 in the representation of the
measuring tool on the graphics page).
If the text of the warning label is not in your national
language, stick the provided warning label in your
national language over it before operating for the first
time.
Do not direct the laser beam at persons or animals and
do not stare into the laser beam yourself. This measur-
ing tool produces laser class 2 laser radiation according to
IEC 60825-1. This can lead to persons being blinded.
Do not use the laser viewing glasses as safety goggles.
The laser viewing glasses are used for improved visualisa-
tion of the laser beam, but they do not protect against laser
radiation.
Do not use the laser viewing glasses as sun glasses or in
traffic. The laser viewing glasses do not afford complete
UV protection and reduce colour perception.
Have the measuring tool repaired only through quali-
fied specialists using original spare parts. This ensures
that the safety of the measuring tool is maintained.
Do not allow children to use the laser measuring tool
without supervision. They could unintentionally blind
other persons or themselves.
Do not operate the measuring tool in explosive environ-
ments, such as in the presence of flammable liquids,
gases or dusts. Sparks can be created in the measuring
tool which may ignite the dust or fumes.
Product Description and Specifica-
tions
Intended Use
The measuring tool is intended for measuring distances,
lengths, heights, clearances, and for the calculation of areas
and volumes. The measuring tool is suitable for measuring in-
doors and outdoors.
Technical Data
Digital Laser Rangefinder GLM 7000
Article number
3 601 K72 4..
Measuring range
0,05 –70 m
A)
Measuring accuracy (typically) ±1.5mm
B)
Lowest indication unit 1mm
Operating temperature
–10 °C...+50 °C
C)
Storage temperature –20 °C...+70 °C
Relative air humidity, max.
90 %
Laser class
2
Laser type
635 nm, <1 mW
Laser beam diameter (at 25 °C) approx.
–at 10m distance
–at 70m distance
6mm
48 mm
Automatic switch-off after approx.
–Laser
– Measuring tool (without measurement)
20 s
5min
Batteries
Rechargeable batteries
2 x 1.5 V LR03 (AAA)
2x1.2VHR03(AAA)
OBJ_BUCH-1548-002.book Page 6 Monday, March 25, 2013 11:55 AM
