Technical Data
Assembly
Auxiliary Handle (see figure A) (GSB 13/
GSB 13 RE/GSB 16/GSB 16 RE)
f Operate your power tool only with the auxil-
iary handle 11.
The auxiliary handle 11 can be set to any position
for a secure and low-fatigue working positure.
Turn the wing bolt for adjustment of the auxiliary
handle 10 in counterclockwise direction and set
the auxiliary handle 11 to the required position.
Then tighten the wing bolt 10 again in clockwise
direction.
Adjusting the Drilling Depth (see figure A)
The required drilling depth X can be set with the
depth stop 12.
Press the button for the depth stop adjustment 9
and insert the depth stop into the auxiliary han-
dle 11.
Pull out the depth stop until the distance be-
tween the tip of the drill bit and the tip of the
depth stop correspond with the desired drilling
depth X.
Hammer Drill GSB ...
Professional
10 10 RE 13 13 RE 16 16 RE
Article number
3 601 ... B16 0.. B16 1.. B17 0.. B17 1.. B18 0.. B18 1..
Rated power input
W 500 500 600 600 701 701
Output power
W 250 250 301 301 351 351
No-load speed
rpm 2600 0 – 2600 2800 0 –2800 3000 0 – 3000
Rotational speed under
load (max.)
rpm 1610 1610 1570 1570 1640 1640
Impact rate
bpm 25700 25700 25070 25070 26270 26270
Rated torque
Nm 1.5 1.5 1.8 1.8 2.0 2.0
Speed Preselection
– –– –– z
Right/left rotation
– z – z – z
Spindle collar dia.
mm 43 43 43 43 43 43
Max. drilling dia.
–Concrete
– Steel
–Wood
mm
mm
mm
10
8
20
10
8
20
13
10
25
13
10
25
16
12
30
16
12
30
Chuck clamping range
mm 1.5 – 10 1.5 – 10 1.5 – 13 1.5 – 13 1.5 – 13 1.5– 13
Weight according to
EPTA-Procedure
01/2003
kg 1.5 1.5 1.7 1.7 1.9 1.9
Protection class
/II /II /II /II /II /II
The values given are valid for nominal voltages [U] of 230/240 V. For lower voltages and models for specific countries,
these values can vary.
Please observe the article number on the type plate of your power tool. The trade names of individual tools may vary.
OBJ_BUCH-61-005.book Page 9 Thursday, November 15, 2007 3:48 PM

Bosch GSB 13 RE Specifications

General

Power Input	600 W
No-load Speed	0 - 2800 rpm
Chuck Capacity	1.5 - 13 mm
Drilling Diameter in Concrete	13 mm
Drilling Diameter in Wood	25 mm
Drilling Diameter in Steel	10 mm
Weight	1.8 kg
Power Output	301 W
Drilling Diameter in Masonry	15 mm
Impact Rate at No-load Speed	0 - 44800 bpm
Max Torque	10.8 Nm
Length	266 mm
