f When working with the power tool, always
hold it firmly with both hands and provide
for a secure stance. The power tool is guided
more secure with both hands.
f Secure the workpiece. A workpiece clamped
with clamping devices or in a vice is held more
secure than by hand.
f Keep your workplace clean. Blends of mate-
rials are particularly dangerous. Dust from
light alloys can burn or explode.
f Always wait until the power tool has come to
a complete stop before placing it down. The
tool insert can jam and lead to loss of control
over the power tool.
f Do not use the power tool with a damaged
cord. Do not touch the damaged cord and
pull the plug from the outlet when the cord
is damaged while working. Damaged cords
increase the risk of an electric shock.
Functional Description
Read all safety warnings and all in-
structions. Failure to follow the
warnings and instructions may result
in electric shock, fire and/or serious
injury.
While reading the operating instructions, unfold
the graphics page for the tool and leave it open.
Intended Use
The machine is intended for impact drilling in
brick, concrete and stone as well as for drilling in
wood, metal and plastic. Machines with electron-
ic control and right/left rotation are also suitable
for driving screws in/out and thread-cutting.
Product Features
The numbering of the product features refers to
the illustration of the power tool on the graphics
page.
1 Keyless chuck*
2 Front sleeve
3 Rear sleeve
4 “Drilling/Impact Drilling” selector switch
5 Lock-on button for On/Off switch
6 On/Off switch
7 Dial control for speed preselection
(GSB 16 RE)
8 Rotational direction switch
(GSB 10 RE/GSB 13 RE/GSB 16 RE)
9 Button for depth stop adjustment
10 Wing bolt for adjustment of auxiliary handle
11 Auxiliary handle*
12 Depth stop*
13 Chuck key*
14 Key-type drill chuck*
15 Universal bit holder*
16 Screwdriver bit*
17 Hex key**
18 Open-end wrench**
*The accessories illustrated or described are not in-
cluded as standard delivery.
**Commercially available (not included in the delivery
scope)
