ﺎﻫ ﻪﺑﺮﺿ ﺩﺍﺪﻌﺗ ﻭ ﺖﻋﺮﺳ ﻢﯿﻈﻨﺗ ﻩﻮﺤﻧ
(GSB 10 RE / GSB 13 RE / GSB 16 RE)
ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﻥﺩﻮﺑ ﻦﺷﻭﺭ ﺖﻟﺎﺣ ﺭﺩ ﺍﺭ ﻪﺑﺮﺿ ﺩﺍﺪﻌﺗ/ﺖﻋﺮﺳ ﺪﯿﻧﺍﻮﺘﯿﻣ ﺎﻤﺷ
ﺭﺎﺸﻓ ﺍﺭ 6 ﻞﺻﻭ ﻭ ﻊﻄﻗ ﺪﯿﻠﮐ ﺪﺣ ﻪﭼ ﺎﺗ ﻪﮑﻨﯾﺍ ﺐﺴﺣ ﺮﺑ یﺪﻨﺑ ﻪﺟﺭﺩ ﻥﻭﺪﺑ
.ﺪﯿﻨﮐ ﻢﯿﻈﻨﺗ ،ﺪﯿﻫﺪﺑ
ﺎﻫ ﻪﺑﺮﺿ ﺩﺍﺪﻌﺗ ﻭ ﺭﻮﺗﻮﻣ ﺭﻭﺩ ﺕﺪﺷ
6 ﻞﺻﻭ ﻭ ﻊﻄﻗ ﺪﯿﻠﮐ یﻭﺭ ﻡﺍﺭﺁ ﺭﺎﺸﻓ
ﺎﻫ ﻪﺑﺮﺿ ﺩﺍﺪﻌﺗ ﻭ ﺖﻋﺮﺳ ﺶﯾﺍﺰﻓﺍ ﺚﻋﺎﺑ ﺭﺎﺸﻓ ﺶﯾﺍﺰﻓﺍ .ﺪﻫﺪﯿﻣ ﺶﻫﺎﮐ ﺍﺭ
.ﺩﻮﺸﯿﻣ
(GSB 16 RE) ﺎﻫ ﻪﺑﺮﺿ ﺩﺍﺪﻌﺗ ﻭ ﺖﻋﺮﺳ ﺏﺎﺨﺘﻧﺍ ﻩﻮﺤﻧ
ﻥﺍﻮﺘﯿﻣ ،ﺖﻋﺮﺳ ﺏﺎﺨﺘﻧﺍ ﻭ ﻢﯿﻈﻨﺗ یﺍﺮﺑ
7 ﺶﺧﺮﭼ ﻞﺑﺎﻗ ﺪﯿﻠﮐ ﻪﻠﯿﺳﻮﺑ
ﺰﯿﻧ (ﺩﺮﮐﺭﺎﮐ) ﻩﺎﮕﺘﺳﺩ ﺖﮐﺮﺣ ﻝﺎﺣﺭﺩ ﺍﺭ ﻡﺯﻻ یﺎﻫ ﻪﺑﺮﺿ ﺩﺍﺪﻌﺗ ﻭ ﺖﻋﺮﺳ
.ﺩﺮﮐ ﻢﯿﻈﻨﺗ
ﺭﺎﮐ ﻂﯾﺍﺮﺷ ﻭ ﺭﺎﮐ ﻪﻌﻄﻗ ﺲﻨﺟ ﻪﺑ ﺎﻫ ﻪﺑﺮﺿ ﺩﺍﺪﻌﺗ ﻭ ﺖﻋﺮﺳ ﻥﺍﺰﯿﻣ
.ﺪﯾﺁ ﯽﻣ ﺖﺳﺪﺑ ﯽﻠﻤﻋ ﮧﺑﺮﲡ ﻖﺒﻃ ﻭ ﻪﺘﺷﺍﺩ ﯽﮕﺘﺴﺑ
ﯽﻠﻤﻋ یﺎﻫ ﯽﺋﺎﻤﻨﻫﺍﺭ
.ﺪﯿﻫﺩ ﺭﺍﺮﻗ ﻩﺮﻬﻣ ﺎﯾ ﻭ ﭻﯿﭘ یﻭﺭ ﺵﻮﻣﺎﺧ ﺖﻟﺎﺣ ﺭﺩ ﺎﻬﻨﺗ ﺍﺭ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ
◀
.ﺩﺭﺍﺩ ﺩﻮﺟﻭ ﺶﺧﺮﭼ ﻝﺎﺣ ﺭﺩ ﺭﺍﺰﺑﺍ ﺵﺰﻐﻟ ﻥﺎﮑﻣﺍ
ﻥﺪﺷ ﮏﻨﺧ یﺍﺮﺑ ﺍﺭ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ ﯽﺘﺴﯾﺎﺑ ،ﻢﮐ ﺖﻋﺮﺳ ﺖﲢ ﺭﺎﮐ ﯽﺗﺪﻣ ﺯﺍ ﺲﭘ
.ﺪﯾﺯﺍﺪﻧﺍ ﺭﺎﮑﺑ ﺩﺍﺯﺁ ﺖﻟﺎﺣ ﺭﺩ ﺖﻋﺮﺳ ﺮﺜﮐﺍﺪﺣ ﺎﺑ ﻪﻘﯿﻗﺩ
3
ﹰ
ﺎﺒﯾﺮﻘﺗ ﺕﺪﻣ ﻪﺑ
ﺖﻣﻼﻋ یﻭﺭ ﺍﺭ 4 ﺩﺮﮑﻠﻤﻋ ﻉﻮﻧ ﺮﯿﯿﻐﺗ ﺪﯿﻠﮐ ﯽﺷﺎﮐ ﻥﺩﺮﮐ ﺥﺍﺭﻮﺳ یﺍﺮﺑ
ﻉﻮﻧ ﺮﯿﯿﻐﺗ ﺪﯿﻠﮐ ﯽﺷﺎﮐ ﻥﺩﺮﮐ ﺥﺍﺭﻮﺳ ﺯﺍ ﺲﭘ .ﺪﯿﻫﺪﺑ ﺭﺍﺮﻗ «یﺭﺎﮐ ﺥﺍﺭﻮﺳ»
ﺭﺎﮐ ﻪﺑﺮﺿ ﺎﺑ ﻭ ﻩﺩﺍﺩ ﺭﺍﺮﻗ «یﺍ ﻪﺑﺮﺿ یﺭﺎﮐ ﻞﯾﺭﺩ» ﺖﻣﻼﻋ یﻭﺭ ﺍﺭ ﺩﺮﮑﻠﻤﻋ
.ﺪﯿﻨﮐ
ﺖﺨﺳ ﺰﻠﻓ یﺎﻫ ﻪﺘﻣ ﺯﺍ یﺮﺟﺁ ﺕﺎﻌﻄﻗ ﻭ ﯽﮕﻨﺳ ﺩﺍﻮﻣ ،ﱳﺑ یﻭﺭ ﺭﺎﮐ یﺍﺮﺑ
.ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ
،HSS ﺲﻨﺟ ﺯﺍ ﺰﯿﺗ ﻭ ﻢﻟﺎﺳ یﺎﻫ ﻪﺘﻣ ﺯﺍ ﻂﻘﻓ ﺕﺍﺰﻠﻓ ﺭﺩ یﺭﺎﮐ ﻪﺘﻣ یﺍﺮﺑ
ﺖﮐﺮﺷ ﺕﺎﻘﻠﻌﺘﻣ ﻭ ﺭﺍﺰﺑﺍ ﺖﺴﯿﻟ .ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ (HSS = ﻊﯾﺮﺳ یﻮﻗ ﺩﻻﻮﻓ)
.ﺪﺷﺎﺒﯿﻣ ﺭﺍﺰﺑﺍ ﺖﯿﻔﯿﮐ ﻦﯾﺮﺘﻬﺑ ﻩﺪﻨﻨﮐ ﻦﯿﻤﻀﺗ ﺵﻮﺑ
ﺮﻄﻗ ﺎﺑ ﯽﯾﺎﻫ ﻪﺘﻣ ﺪﯿﻧﺍﻮﺘﯿﻣ (ﺕﺎﻘﻠﻌﺘﻣ) ﻪﺘﻣ ﻥﺩﺮﮐ ﺰﯿﺗ ﺭﺍﺰﺑﺍ ﻪﻠﯿﺳﻮﺑ
.ﺪﯿﻨﮐ ﺰﯿﺗ ﯽﺘﺣﺍﺭ ﻪﺑ ﺍﺭ ﺮﺘﻤﯿﻠﯿﻣ 2,5 – 10
GSB 16 RE
(ﺕﺎﻘﻠﻌﺘﻣ) ﻪﺘﻣ ﻪﯾﺎﭘ ﮏﯾ ﺯﺍ ،ﯽﺻﺎﺧ ﻭ ﻖﯿﻗﺩ یﺎﻫﺭﺎﮐ ﺯﺍ ﯽﺧﺮﺑ ﻡﺎﳒﺍ یﺍﺮﺑ
.ﺪﯿﻨﮐ ﻩﺩﺎﻔﺘﺳﺍ
ﻪﻌﻄﻗ ﻥﺍﻮﺘﯿﻣ ،ﺩﻮﺸﯿﻣ ﻪﺿﺮﻋ ﻪﻧﺎﮔﺍﺪﺟ ﺭﻮﻄﺑ ﻪﮐ ﻩﺎﮕﺘﺳﺩ ﻝﺎﺼﺗﺍ ﻩﺮﯿﮔ ﺎﺑ
ﺢﻧﺍﻮﺳ ﻭ ﻪﻌﻄﻗ ﻥﺪﺷ ﺞﮐ ﺯﺍ ﻦﯾﺍ .ﺩﻮﳕ ﺭﺎﻬﻣ ﻢﮑﺤﻣ ﻦﺌﻤﻄﻣ ﺭﻮﻄﺑ ﺍﺭ ﺭﺎﮐ
.ﺩﺭﻭﺁ ﯽﻣ ﻞﻤﻌﺑ یﺮﯿﮔﻮﻠﺟ ﯽﻟﺎﻤﺘﺣﺍ
ﺲﯾﻭﺮﺳ ﻭ ﺖﺒﻗﺍﺮﻣ
ﻩﺎﮕﺘﺳﺩ ﻥﺩﺮﮐ ﺰﯿﲤ ﻭ ﺮﯿﻤﻌﺗ ،ﺖﺒﻗﺍﺮﻣ
ﻝﺎﺼﺗﺍ ﻪﺧﺎﺷﻭﺩ ،ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ یﻭﺭ ﺮﺑ یﺭﺎﮐ ﻪﻧﻮﮔﺮﻫ ﻡﺎﳒﺍ ﺯﺍ ﺶﯿﭘ
◀
.ﺪﯿﺸﮑﺑ ﻥﻭﺮﯿﺑ ﻕﺮﺑ ﺰﯾﺮﭘ ﻞﺧﺍﺩ ﺯﺍ ﺍﺮﻧﺁ
ﯽﻨﻤﯾﺍ ﺎﺗ ،ﺪﯾﺭﺍﺩ ﻩﺎﮕﻧ ﺰﯿﲤ ﺍﺮﻧﺁ ﻪﯾﻮﻬﺗ یﺎﻫﺭﺎﯿﺷ ﻭ ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ
◀
.ﺩﺩﺮﮔ ﻦﯿﻤﻀﺗ ﺭﺎﮐ ﺭﺩ ﺎﻤﺷ
ﻞﺣﺍﺮﻣ ﺭﺩ ﻪﮐ یﺭﺎﯿﺴﺑ ﺖﻗﺩ ﺩﻮﺟﻭ ﺎﺑ ،ﯽﮑﯾﺮﺘﮑﻟﺍ ﺭﺍﺰﺑﺍ ﻥﺩﺎﺘﻓﺍ ﺭﺎﮐ ﺯﺍ ﺕﺭﻮﺻﺭﺩ
ﺯﺍ ﯽﮑﯾ ﻪﺑ ﻥﺁ ﺮﯿﻤﻌﺗ یﺍﺮﺑ ﺪﯾﺎﺑ ،ﺖﺳﺍ ﻪﺘﻓﺮﮔ ﺕﺭﻮﺻ ﻥﺁ ﺶﯾﺎﻣﺯﺁ ﻭ ﺪﯿﻟﻮﺗ
ﻪﻌﺟﺍﺮﻣ ﺵﻮﺑ ﯽﻗﺮﺑ ﺕﻻﺁﺭﺍﺰﺑﺍ ﺵﻭﺮﻓ ﺯﺍ ﺲﭘ ﺕﺎﻣﺪﺧ ﻭ ﺯﺎﺠﻣ یﺎﻫ ﻩﺎﮔﺮﯿﻤﻌﺗ
.ﺪﯿﻨﮐ
ﻩﺭﺎﻤﺷ
ﹰ
ﺎﻤﺘﺣ ،ﺕﺎﻘﻠﻌﺘﻣ ﻭ ﯽﮐﺪﯾ ﺭﺍﺰﺑﺍ ﺵﺭﺎﻔﺳ ﺎﯾ ﻭ ﻝﺍﻮﺌﺳ ﻪﻧﻮﮔﺮﻫ یﺍﺮﺑ
.ﺪﯿﻫﺩ ﻉﻼﻃﺍ ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ یﻭﺭ ﺐﺴﭼﺮﺑ ﻖﺑﺎﻄﻣ ﺍﺭ ﻻﺎﮐ ﯽﻤﻗﺭ ﻩﺩ ﯽﻨﻓ
ﻥﺎﯾﺮﺘﺸﻣ ﺎﺑ ﻩﺭﻭﺎﺸﻣ ﻭ ﺵﻭﺮﻓ ﺯﺍ ﺲﭘ ﺕﺎﻣﺪﺧ
ﻭ ﺲﯾﻭﺮﺳ ،ﺕﺍﺮﯿﻤﻌﺗ ﻩﺭﺎﺑ ﺭﺩ ﺎﻤﺷ ﺕﻻﺍﻮﺌﺳ ﻪﺑ ﺵﻭﺮﻓ ﺯﺍ ﺲﭘ ﺕﺎﻣﺪﺧ ﺮﺘﻓﺩ
ﺕﺎﻋﻼﻃﺍ ﻭ ﺮﯾﻭﺎﺼﺗ .ﺩﺍﺩ ﺪﻫﺍﻮﺧ ﺦﺳﺎﭘ ﺕﺎﻘﻠﻌﺘﻣ ﻭ ﯽﮐﺪﯾ ﺕﺎﻌﻄﻗ ﻦﯿﻨﭽﻤﻫ
ﻞﯾﺫ ﻩﺩﺮﺒﻣﺎﻧ ﺖﯾﺎﺳ ﺭﺩ ﺪﯿﻧﺍﻮﺘﯿﻣ ﺍﺭ ﺕﺎﻘﻠﻌﺘﻣ ﻭ ﯽﮐﺪﯾ ﺕﺎﻌﻄﻗ ﻩﺭﺎﺑ ﺭﺩ
:ﺪﯿﯾﺎﳕ ﻮﺠﺘﺴﺟ
www.bosch-pt.com
ﺕﻻﺍﻮﺌﺳ ﻪﺑ ﻞﯿﻣ ﻝﺎﻤﮐ ﺎﺑ ﺵﻮﺑ ﺖﮐﺮﺷ ﺵﻭﺮﻓ ﺯﺍ ﺲﭘ ﺕﺎﻣﺪﺧ ﺭﻭﺎﺸﻣ ﻢﯿﺗ
ﺦﺳﺎﭘ ﺕﺎﻘﻠﻌﺘﻣ ﻭ ﺕﻻﻮﺼﺤﻣ ﻢﯿﻈﻨﺗ ﻭ ﻩﺩﺎﻔﺘﺳﺍ ﺯﺮﻃ ،ﺪﯾﺮﺧ ﻩﺭﺎﺑ ﺭﺩ ﺎﻤﺷ
.ﺪﻫﺪﯿﻣ
ﺩﺍﺮﻓﺍ ﻪﺑ ﻂﻘﻓ ﯽﻛﺪﻳ ﺭﺍﺰﺑﺍ ﻪﻴﻬﺗ ﻭ ﻩﺎﮕﺘﺳﺩ ﺮﻴﻤﻌﺗ ،ﯽﺘﻧﺍﺭﺎﮔ ﺯﺍ ﻩﺩﺎﻔﺘﺳﺍ یﺍﺮﺑ
.ﺪﻴﻨﻛ ﻪﻌﺟﺍﺮﻣ ﺺﺼﺨﺘﻣ
ﻩﺎﮕﺘﺳﺩ ﻥﺩﺮﮐ ﺝﺭﺎﺧ ﻩﺩﺭ ﺯﺍ
ﻂﯿﺤﻣ ﻆﻔﺣ ﺕﺍﺭﺮﻘﻣ ﻖﺒﻃ ﺪﯾﺎﺑ ،ﻥﺁ یﺪﻨﺑ ﻪﺘﺴﺑ ﻭ ﺕﺎﻘﻠﻌﺘﻣ ،ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ
.ﺪﻧﻮﺷ ﺖﻓﺎﯾﺯﺎﺑ ﻭ ﺝﺭﺎﺧ ﻩﺩﺭ ﺯﺍ ﺖﺴﯾﺯ
!ﺪﯾﺯﺍﺪﻧﺎﯿﻧ ﯽﮕﻧﺎﺧ ﻥﺍﺩ ﻪﻟﺎﺑﺯ ﻞﺧﺍﺩ ﺍﺭ ﯽﻗﺮﺑ یﺎﻫﺭﺍﺰﺑﺍ
.ﺖﺳﺍ ﻅﻮﻔﺤﻣ یﺮﯿﯿﻐﺗ ﻪﻧﻮﮔﺮﻫ ﻖﺣ
