Interior components diagram and parts list
55
Item Description Reference
1 Heat exchanger 8 705 406 421
2 Heat exchanger top gasket 8 704 701 052
3 Condensing exchanger inlet 8 705 700 159
4 Overheat sensor (ECO) 8 707 206 204
5 Heat exchanger bottom gasket 8 704 701 054
6 Site window 8 701 000 401
7 Ignition group 8 701 302 249
8 Heat exchanger O-ring 8 700 205 147
9 Rubber grommet 8 710 303 027
10 Connecting pipe 8 700 715 403
11 Pipe connection clip 8 701 201 028
12 Condensing exchanger gasket 8 704 701 090
13 Condensing exchanger nut 8 703 301 157
14 Condensing heat exchanger 8 705 700 161
15 Condensing exchanger left side 8 705 700 162
16 Condensing exchanger side gasket 8 704 701 091
17 Allen screw 2 918 060 162
18 Condensing exchanger right side 8 705 700 163
19 Screw 2 910 611 496
20 Fincoil O-ring 8 700 205 226
21 Condensing fincoil 8 700 715 402
22 O-ring 8 700 205 228
23 Condensate drain connector 8 705 506 838
24 Condensate drain connector gasket 8 704 701 092
25 Exhaust temperature sensor 8 707 206 459
26 Washer 8 704 701 097
27 U-bend pipe 8 703 305 352
28 Condensing exchanger clip 8 701 300 023
29 Offset pipe 8 700 715 396
30 Flue gas collector 8 705 506 841
31 Cold water pipe upper 8 700 715 398
32 Siphon 8 705 202 141
33 Condensate drain pipe 8 700 703 177
34 Condensate drain pipe clip 8 716 102 607
35 Condensate drain pipe O-ring 8 704 701 094
Table 22
