Function Menu Description
Output Switch
Test
On Demand Tests This function tests output devices
such as actuators, solenoids, and
relays controlled by the powertrain
computer module. This test will
toggle the devices ON / OFF and a
voltmeter can be used to verify the
signal is actually reaching the
output device. This function only
applies to Ford OBD I vehicles.
Pre-Trigger
Setup
System Setup This function is used to configure
how many Pre-Trigger frames are
stored prior to beginning a record-
ing.
Print Data Main, Diagnostic,
Datastream, Diag-
nostic Codes,
Special Tests, On
Demand Tests
Prints diagnostic information
stored in the Scan Tool. (Refer to
Users Manual)
Print Header System Setup Allows the user to turn off the Scan
Tool printing the currently-selected
vehicle prior to the retrieved vehi-
cle data when selecting items from
the Print Data menu.
Program
Mode
System Setup Used for updating the Scan Tool.
Quick Test System Setup Allows the user to turn off the Scan
Tool performing Read Codes and
I/M Monitors after vehicle selection
when the Scan Tool is connected
to the vehicle.
