Bosch PSB 0004 A - Installation; Safety Warnings during Installation; IP30 Conformity Notice; Technical Data

Power supply housings for wall mounting Installation | en 11
Bosch Sicherheitssysteme GmbH Quick installation guide 2019.12 | 6 | 4.998.154.010
1 Installation
Danger!
Risk of electric shock!
Death or serious injury through contact with live parts and wires.
Make sure that the device is disconnected from the power source before installation and
maintenance.
Notice!
IP30 conformity
If you break out the pre-cut cable entry points, ensure that the IP30 conformity is still
established, e.g. by using cable glands.
2 Technical data
PSS 0002 A
Housing material Sheet steel, painted
Housing color Slate gray RAL 7015
Front: anthracite gray RAL 7016
Dimensions Approx. 267 x 440 x 149mm
Weight Approx. 6.4 kg
PSB 0004 A
Housing material Sheet steel, painted
Housing color Slate gray RAL 7015
Front: anthracite gray RAL 7016
Dimensions Approx. 502 x 440 x 149mm
Weight Approx. 11.4 kg
