24/88 Bosch Rexroth AG SE352/SE352M | 3 609 929 B61/2008-09
Slot for the mass storage (X6C1)
This interface is intended for the use of the
CF350 mass storage.
5 Transport and storage
For storing and transporting the product,
always observe the ambient conditions
specified in the technical data (see
“Technical data” on page 29).
6 Assembly
When installing the product, always observe
the ambient conditions specified in the
technical data (see “Technical data” on
page 29).
Installing SE352/SE352M control unit
ATTENTION
Damage due to improper assembly!
Damage to the connections
y Only use mass storage from Rexroth.
y Insert the CF350 mass storage into the
SE352/SE352M control unit with the
plug-in connections facing the front, so
the “Rexroth” product label (front side of
the card) is visible.
CAUTION
Risk of damage to persons
and property!
Assembly of the SE352/SE352M
control unit requires basic me-
chanical and electrical knowl-
edge.
y Only qualified personnel (see
“Personnel qualifications” on
page 18) are authorized to as-
semble the SE352/SE352M
control unit.
y Measures to prevent electro-
static discharge (ESD protec-
tion) must be undertaken to
protect the module and system
components during all assem-
bly work.
CAUTION
Risk of injuries when
assembling under voltage!
If you do not switch off the power
supply before assembling the
SE352/SE352M control unit, you
may be injured or the device or
system components may be dam-
aged.
y Switch off power supply for the
relevant system component be-
fore assembling the SE352/
SE352M control unit.
