51
VI.
VI.
Component Access/Replacement
Component Access/Replacement
Heaters &
Heaters &
NTC’s
NTC’s
–
–
Removal & Installation (1)
Removal & Installation (1)
Removing & Installing NTC:
Remove heater assembly -- NTC is located on
top of heater assembly.
Disconnect wires after noting connections
(since NTC & Hi-Limit are included in the
same part -- # 165281).
Remove NTC cover, pull NTC holding tabs
apart and pull NTC out of heater.
Disconnect wires Remove cover & pull tabs Remove NTC
Hi-Limit
NTC
HINT: If needed, use rinse-aid to
lubricate gaskets to make it easier to
assemble heater to sump and pump.
NOTE: Softer bearing & non-softer
bearing heater assemblies, circulation
pumps and sumps cannot
be mixed
and matched. Softer bearing heaters
don’t fit in older models and older
heaters don’t fit in softer bearing
models.
NTC w/ Hi-Limit
NOTE: To remove flow
switch, carefully pry
housing away from switch
(until tabs clear switch),
then snap switch out.
