VIII.

Troubleshooting

Dispenser

–

Replacing Dispenser Doors

Most dispenser problems occur from dispenser doors being

damaged or pulled off (due to misuse). Please follow the

instructions below when replacing doors.

 Connect spring to

door & dispenser

housing posts.

 While keeping

spring attached to

posts, carefully

slide door onto

housing -- making

sure door tabs

engage dispenser

door rails.

 Door levers don’t

need to be preset

during installation.

Door

Dispenser with spring

Attach

spring

to post

HINT: Make sure door tabs

engage dispenser door rails.

Slide door

into rails

HINT: To close dispenser doors, slide doors closed, then push

white lever until lever locks (showing doors are closed). Levers

don’t need to be preset during installation.

Open

Closed
