Bosch Thermotechnology Corp. reserves the right to make changes without notice due
to continuing engineering and technological advances |
BTC 760108301 E | 02.2014
Bosch Thermotechnology Corp.
Londonderry, NH • Ft. Lauderdale, FL
Tel: 1-866-642-3198 Fax: 1-954-776-5529 www.bosch-climate.us
Engineering Submittal Sheet
SM Series
Residential Geothermal Heat Pumps
2nd data plate for units with EH option - Constant Torque ECM motor
Model
Electric
Heater Rated
kW
Stage
Heater
Watts
Heater
Amps
Motor
FLA (A)
Circuit MCA MOCP
240V 208V 240V 208V Fuses 240V 208V 240V 208V
SM024 4.8 1 4,800 3,600 20.0 17.3 2.8 - 28.5 25.1 30 30
SM036 4.8 1 4,800 3,600 20.0 17.3 6.0 - 32.5 29.1 35 30
SM036 9.6 1 9,600 7,200 40.0 34.6 6.0 - 57.5 50.8 60 60
SM048 4.8 1 4,800 3,600 20.0 17.3 6.0 - 32.5 29.1 35 30
SM048 9.6 1 9,600 7,200 40.0 34.6 6.0 - 57.5 50.8 60 60
SM048 14.4 2 14,400 10,800 60 51.9 6
F1/F2
82.5 72.4 90 80
F3/F4
SM060 4.8 1 4,800 3,600 20.0 17.3 7.6 - 34.5 31.1 35 35
SM060 9.6 1 9,600 7,200 40.0 34.6 7.6 - 59.5 52.8 60 60
SM060 14.4 2 14,400 10,800 60 51.9 7.6
F1/F2
84.5 74.4 90 80
F3/F4
SM060 19.2 2 19,200 14,000 80 69.2 7.6
F1/F2
109.5 96.0 110 100
F3/F4
SM070 4.8 1 4,800 3,600 20.0 17.3 7.6 - 34.5 31.1 35 35
SM070 9.6 1 9,600 7,200 40.0 34.6 7.6 - 59.5 52.8 60 60
SM070 14.4 2 14,400 10,800 60 51.9 7.6
F1/F2
84.5 74.4 90 80
F3/F4
SM070 19.2 2 19,200 14,000 80 69.2 7.6
F1/F2
109.5 96.0 110 100
F3/F4
