32
Bosch Security Systems 09/07 BLCC500R FTR1.02
Copyright © 2007 E&OE
Inputs > Tamper Inputs >
Tamper Options MENU 3-6-0
1 Display Panel Tamper Y
2 Report Panel Tamper Y
3 Audible Panel Tamper Y
4 Display Expander Tamper Y
5 Report Expander Tamper Y
6 Audible Expander Tamper Y
7 Reserved N
8 Reserved N
This location is a Bit option field. Press Keys [1] – [8] to turn ON and
OFF the required options. The option is selected or ON when the
coresponding zone indicator is on. Press [OK] To Save when finished.
Inputs > Input Testing >
Walk Test All Zones
MENU 3-9-0
Walk Test A Zones
MENU 3-9-1
Inputs > Input Testing >
Sensor Watch Time
MENU 3-9-2
0 3 0
(*** System Wide Parameter ***)
DAYS
Enter 0 – 255 + [OK] To Program The Sensor Watch Time In Days
(0 = Disabled)
Outputs > Commands >
Output Status
MENU 4-0-0
Turn Output On/Off
MENU 4-0-1
Outputs > Properties >
Output Name
MENU 4-1-0
O u t p u t 1 N a m e
Use [] and [] Keys To Scroll the Cursor Left and Right. Use Keys [0]
– [9] + [] and [] To Select Characters. When finished press [OK] To
Save. Press [OFF] To Clear From The Current Cursor Position.
Outputs > Properties >
Event Type
MENU 4-1-1
0 0 0
Enter desired Event type 0 – 255 + [OK].
See Output Event Type table for available options.
Outputs > Properties >
Event Assignment
MENU 4-1-2
0 0 1
Enter 0 to 255 to program the Area, User, Zone, Keypad or Access
Group Number You Want The Output To Follow Then Press [OK].
(0 = Unrestricted all Areas, Users, Zones etc)
Table 20: Output Default Table
