Bosch SPLIT ODU Series - Page 2

Service Guide
(2 of 25)
(for 1 Phase model)
Description Spec Qty Detail
1 Felt
White
felt(260x5x1 mm) 8
For prevent panel contact vibration
(for external parts)
2 Insulation
Black
insulation,foam
(500x10x3 mm)
5
For prevent panel contact vibration
(for internal parts)
3 Damper
Ø
19.05 , 200g 4
For reduce pipe
vibration
4 Damper
Ø
12.7 , 200g 2
For reduce pipe
vibration
5
Damper
(Rubber)
Black
rectangular damper
(100 x 30 x 5 mm)
1
For reduce
pipe vibration
6
Damping
sheet
Black rubber sheet
(608
x 172 x 5 mm)
1
For prevent panel contact vibration
7 Holder
Still
holder 2
For prevent condenser
contact vibration
In addition, Cable ties are included to prevent Damper Slipping down.
Description Spec Qty Detail
1 Felt
White
felt(260x5x1 mm) 8
For prevent panel contact vibration
(for external parts)
2 Insulation
Black
insulation,foam
(500x10x3 mm)
5
For prevent panel contact vibration
(for internal parts)
3 Damper
Ø
19.05 , 200g 3
For reduce pipe
vibration
4 Damper
Ø
12.7 , 200g 2
For reduce pipe
vibration
5
Damper
(Rubber)
Black
rectangular damper
(100 x 30 x 5 mm)
1
For reduce
pipe vibration
6
Damping
sheet
Black rubber sheet
(608
x 172 x 5 mm)
1
For prevent panel contact vibration
7 Holder
Still
holder 2
For prevent condenser
contact vibration
Parts provided with service kit (for 3 Phase model)
In addition, Cable ties are included to prevent Damper Slipping down.
