SSB 6720892984 (2019/02) US
Service reminder | 49
B.2 Maximum load on outputs (for hardware 905MN1x_3Rf and up)
Device Max Current Max Power
Control and gas valve 0,5 A 60 VA
All pumps together 1,5 A 180 VA
Fan 2,0 A 240 VA
Total external load 4 A 480 VA
All other devices must be powered externally.
B.3 Minimum/Maximum load on air damper output (J3-6)
The output J3-6 is a triac controlled output. This output needs a minimum load of approx. 10VA to work correctly and the max load must be limited to 50VA
@ supply voltage.
Connection an external relay to this output to be able to switch a higher load is only possible when an additional resistor or load is added to make sure the
minimum load requirements are met.
Appendix C - System parameters
C.1 Settings stored in 905PB display
Menu item Sub item / Parameter Range Default Value Units User Level
Language
English
French
Chinese
Italian
English 1: User
Unit type
Metric
Imperial
Metric
°C, Bar
°F, PSI
1: User
Date &Time Date - dd-mm-year 1: User
Time - 00:00 1: User
Time Zone Settings 1: User
Time Zone Correction UTC X 1: User
Daylight Savings Time
Disabled
N,C America, Europe
1: User
Display Settings 1: User
Time Notation 24h, 12h 24h 1: User
Date Order DMY, MDY, YMD DMY 1: User
Day of Month 1-2 digits 2 digits 1: User
Month
Short-Full text
1-2 digits
2 digits 1: User
Year 2-4 digits 4 digits 1: User
Date Separation
Character
-, /, . - 1: User
Day of Week
Disabled
Short Text
Full Text
Short Text 1: User
Seconds Yes, No No 1: User
Cascade Mode
Full option (8 module
TS/BMS)
Basic (16 module ZH)
Full
Basic
Full 1: User
Modbus Address 0..255 1 1: User
Modbus Stop bits 1 - 2 2 1: User
Startup Settings Startup Logo Default 1: User
