Appendix H - Cascade parameter
Specic Parameters Level
(Default) Value Range
°C °F °C °F
Emergency_Mode [-] 1: User
Enable
Enable/
Disabled
Cascade_Setpoint
Cascade CH Setpoint
[°C/°F]
1: User 60 140 40..93 104..200
Boiler_Address [-] 2: Installer 0 0...16 0...16
Emergency_Setpoint [°C/°F] 2: Installer 70 158 20..90 68..194
Delay_Period_Start_Next_Dependent
Start Delay Time
[sec] 2: Installer 180 0..1275
Delay_Period_Stop_Next_Dependent
Stop Delay Time
[sec] 2: Installer 180 0..1275
Delay_Period_Start_Next_Dependent_ Faster
Quick Start Interval
[sec] 2: Installer 30 0..1275
Delay_Period_Stop_Next_Dependent_ Faster
Quick Stop Interval
[sec] 2: Installer 30 0..1275
Hyst_Down_Start_Burner
Start Burner Diff
[°C/°F] 2: Installer 5 9 0..20 0..36
Hyst_Up_Stop_Burner
Stop Burner Diff
[°C/°F] 2: Installer 2 4 0..20 0..36
Hyst_Up_Stop_All
Stop Burner Diff
[°C/°F] 2: Installer
6 11 0..30
0..54
Hyst_Down_Quick_Start
Start Burner Diff in short time
[°C/°F] 2: Installer
10 18 0..20
0..36
Hyst_Up_Quick_Stop
Stop Burner Diff in short time
[°C/°F] 2: Installer
4
7
0..20
0..36
Max_Range_Up_Limit
Calculated setpoint Max offset down
[°C/°F] 2: Installer 20
36 0..20
0..36
Max_Range_Down_Limit
Calculated setpoint Max offset up
[°C/°F] 2: Installer 20 36 0..20 0..36
Start_Modulation_Delay_Factor [-] 2: Installer
60 0..60
0 = Disabled
Next_Burner_Start_Rate [%] 2: Installer 80 10..100
Next_Burner_Stop_Rate [%] 2: Installer 25 10..100
Burnerr_Rotation_Interval [days] 2: Installer
5 0..30
0 = Disabled
Calc_Setp_PID_P [-] 3: Factory 50 0..1275
Calc_Setp_PID_I [-] 3: Factory 50 0..1275
PID_Slew_Rate_Step_UP [°C/100ms] 3: Factory 1,0
0..25,5
0 = Disabled
PID_Slew_Rate_Step_Down [°C/100ms] 3: Factory 1,0
0..255
0 = Disabled
System_Pump_Post_Pump_Time [sec] 2: Installer 30 sec 1..90
