WATERSIDE PRESSURE DROP TABLE
WATER COIL VOLUME
Model
Water
Flow
Rate
(GPM)
Water Side
Pressure Drop
(PSI)
Water Side
Pressure Drop
with Internal
Valve (PSI)
SV007
1.5 0.7 1.0
2 1.1 1.8
2.5 1.7 2.7
SV009
2 1.7 2.3
2.5 2.5 3.5
3 3.5 5.0
SV012
2.5 2.6 3.6
3 3.6 5.0
3.5 4.8 6.7
SV015
3 3.9 5.3
4 6.5 9.1
5 9.8 13.8
SV018
4 2.7 5.2
5 4.0 8.0
6 5.6 11.3
SV024
4 2.8 3.4
6 5.8 7.2
8 9.7 12.3
SV030
5 3.0 4.0
7.5 6.2 8.5
9 8.6 11.9
SV036
6 2.6 4.0
9 5.4 8.6
12 9.1 14.8
SV041
7 3.6 5.6
10 6.9 10.9
13 11.1 17.9
SV042
7 3.6 5.6
10 6.9 10.9
13 11.1 17.8
SV048
8 1.4 2.5
12 2.8 5.4
15 4.2 8.2
SV060
10 2.3 4.1
15 4.8 8.8
18 6.7 12.4
SV070
11 2.9 5.0
16 5.7 10.2
18 7.0 12.7
All values based upon pure water at 70° F.
SV Series Coaxial Coil Volume (gal)
007 0.04
009 0.06
012 0.08
015 0.09
018 0.14
024 0.14
030 0.24
036 0.27
041 0.27
042 0.27
048 0.49
060 0.62
070 0.62
