6.4.3 Loosening the metal bands
The steplessly height-adjustable coffee outlet is braked by metal
bands on which magnets press.
For subsequent removal:
► Press the outlet slide all the way down (1.)
► Insert a flat-tipped screwdriver into the side openings in the
metal bands (A) and prise the metal bands out of the guide
pins by rotating the screwdriver (2.)
6.4.4 Removing the metal bands
► Using a flat-tipped screwdriver, press the metal band (A)
downwards.
► Remove the metal bands (A) and the braking magnets (B).
