Bosch UniversalInspect - Assembly and Power Supply; Power Supply

20 | English
Digital inspection cameraUniversalInspect
Rated voltageV=6
Non-rechargeable batteries (alkaline manganese)4×1.5VLR6(AA)
Operating temperature°C–10to+50
Storage temperature (without batteries)°C–20 to +70
Relative air humidity%5–95
A)
Length of camera cablemm950
Smallest bend radius of camera cablemm30
Camera head diametermm8
Display resolution320×240
Approx. operating timeh4
Weight according to EPTA-Procedure01:2014
(With batteries, without protective bag, without ac-
cessories)
kg0.39
Dimensions (length × width × height)mm161×70×41
Protection rating of camera head and camera cableIP67
Protection rating of housing–
A)Free of condensation
For clear identification of your inspection camera, see the serial number(15) on the type plate.
Assembly
Power supply
The inspection camera can be operated with commercially available batteries.
To open the battery compartment cover(17), press on the locking mechanism(16) and
remove the battery compartment cover(17). Insert the batteries. When inserting the
batteries, ensure that the polarity is correct according to the illustration on the inside of
the battery compartment.
Always replace all the batteries at the same time. Only use batteries from the same man-
ufacturer and which have the same capacity.
u Remove the batteries from the inspection camera when not using it for longer
periods. The batteries can corrode and self-discharge during prolonged storage.
Note: The ribbon(20) in the battery compartment is used to conveniently remove the
batteries.
