(1) Battery charger
(2) Device socket
(3) Device connector
(4) Charger safety instructions
(5) Charging connector
(6) Socket for charging connector
(7) Charging socket cover
(8) Operation/battery charge indicator
(9) Battery on/off button
(10) PowerTube
Product description and specications
Intended Use
In addition to the functions shown here, changes to software relating to
troubleshooting and functional modications may be introduced at any
time.
The Bosch eBike chargers are intended exclusively for charging Bosch
eBike batteries and must not be used for any other purpose.
Product features
The numbering of the components shown refers to the
illustrations on the graphics pages at the beginning of the manual.
Individual illustrations in these operating instructions may differ
slightly from the actual conditions depending on the equipment of
your eBike.
