Operation
Connecting the charger to the mains (see gure A)
- Pay attention to the mains voltage. The voltage of the power source
must match the voltage specied on the rating plate of the charger.
Chargers marked 230 V can also be operated at 220 V. Plug the device
connector (3) of the power cable into the device socket (2) on the
charger. Connect the power cable (country-specic) to the mains.
Charging the removed battery (see gure B)
Switch the battery off and remove it from its holder on the eBike. When
doing so, read and observe the operating instructions of the battery.
- Ensure the battery is placed on clean surfaces only. Avoid getting dirt,
e.g. sand or soil, in the charging socket and contacts in particular. Plug the
charging connector (5) of the charger into the socket (6) on the battery.
Charging the battery on the bike (see gure C)
Switch the battery off. Clean the cover of the charging socket (7). Avoid
getting dirt, e.g. sand or soil, in the charging socket and contacts in
particular. Lift the cover of the charging socket (7) and plug the charging
connector (5) into the charging socket (6).
There is a risk of re due to the charger heating up during charging.
Ensure the battery on the bike is completely dry and placed on a reproof
surface before charging. If this is not possible, remove the battery from
the holder and charge it in a more suitable location. When doing so, read
and observe the operating instructions of the battery.
Charging process
The charging process begins as soon as the charger is connected to the
battery or charging socket on the bike and to the mains.
Note: The charging process is only possible when the temperature of the
eBike battery is within the permitted charging temperature range.
Note: The drive unit is deactivated during the charging process
The battery can be charged with and without the on-board computer.
When charging without the on-board computer, the charging procedure
can be observed on the battery charge indicator. When the on-board
computer is connected, a charging notication appears on the display.
The state of charge is displayed by the battery charge indicator (8) on the
battery and by the bars on the on-board computer.
The LEDs on the battery charge indicator (8) ash during the charging
process. Each solid illuminated LED represents approximately 20 % of
the charging capacity. The ashing LED indicates the next 20 % currently
charging.
Once the eBike battery is fully charged, the LEDs go out immediately
and the on-board computer is switched off. The charging process is
terminated. The state of charge can be displayed for 5 seconds by
pressing the on/off button (9) on the eBike battery.
Disconnect the charger from the mains and the battery from the
charger. When the battery is disconnected from the charger, the battery
is automatically switched off. Note: If you have charged the battery
on the bike, carefully close the charging socket (6) with the cover (7)
after charging, so that no dirt or water can get in. If the charger is not
disconnected from the battery after charging, after a few hours the
charger will switch itself back on, check the state of charge of the battery
and begin the charging procedure again if necessary.
CHARGER START UP
CHARGING
31
