02 - RIDE INFO 2.2 Frame Mounts
11
WARNING: Pay attention to frame decals indicating
the maximum insertion length for screw xings.
Always measure the thread length of screws prior
to installation. Failure to check screw lengths could
damage electrical components and cause serious
injury.
Max.
Thread
Length
Frame Decal
WARNING: Where possible ALWAYS use original xing. Never use a xing
longer than 10mm as longer screws may come into contact with electrical
components.
Max.Thread
Length
10mm
