Bose 802C User Manual

Bose 802C
20 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #19 background imageLoading...
Page #19 background image
Figure 6. Top Cover Connection Diagram
19

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Bose 802C and is the answer not in the manual?

Bose 802C Specifications

General IconGeneral
Weight5 lbs (2.3 kg)
CompatibilityBose 802 Loudspeaker System
FunctionsEqualization, Crossover, Limiting
EqualizationSpecifically tailored for the Bose 802 loudspeaker system
Signal-to-Noise Ratio>90 dB
Power Requirements100-240 V, 50/60 Hz
Input Impedance20 kOhms (balanced)
Dimensions1.75" H x 19" W x 7.8" D (4.4 cm x 48.3 cm x 19.8 cm)
