Setting Up Your Lifestyle
®
Stereo Amplifier
Figure 5
Recommended mounting
hardware
(4) #10 x 1
1
/2 in.
(M5 x 36 mm)
(4) #10 x 2
1
/2 in.
(M5 x 75 mm)
3
/32 in. (2.25 mm)
1
/2 in. (12 mm)
1
/4 in. (6 mm)
(4) #10 (M5)
(4) #10 x 1
1
/2 in.
(M5 x 36 mm)
(4) #10 x 1 in.
(M5 x 25 mm)
You will need:
To mark hole locations, first remove the rubber
feet. Then, hold the amplifier in place and mark
the wall through the clearance holes in the
amplifier enclosure.
Wood wall
Wallboard
Masonry wall
