Bose AV28 User Manual

42
(Resistors continued)
Main PCB 260318-0
Electrical Part List
Reference
Designator
Description Part Number Note
R201 100K, 0603, .1W, 5% 199403-104
R202 100K, 0603, .1W, 5% 199403-104
R203 100K, 0603, .1W, 5% 199403-104
R204 100K, 0603, .1W, 5% 199403-104
R205 100K, 0603, .1W, 5% 199403-104
R206 100K, 0603, .1W, 5% 199403-104
R207 100K, 0603, .1W, 5% 199403-104
R208 100K, 0603, .1W, 5% 199403-104
R209 750 OHM, 0603, .1W, 5% 199403-751
R210 3.9K, 0603, .1W, 5% 199403-392
R211 10 OHM, 0603, .1W, 5% 199403-100
R212 2.2K, 0603, .1W, 5% 199403-222
R213 15 OHM, 0603, .1W, 5% 199403-150
R214 750 OHM, 0603, .1W, 5% 199403-751
R215 3.9K, 0603, .1W, 5% 199403-392
R216 10 OHM, 0603, .1W, 5% 199403-100
R217 2.2K, 0603, .1W, 5% 199403-222
R218 15 OHM, 0603, .1W, 5% 199403-150
R219 560 OHM, 0603, .1W, 5% 199403-561
R220 560 OHM, 0603, .1W, 5% 199403-561
R227 1.0K, 0603, .1W, 1% 191465-1001
R230 4.7K, 0603, .1W, 5% 199403-472
R231 4.7K, 0603, .1W, 5% 199403-472
R233 4.7K, 0603, .1W, 5% 199403-472
R234 4.7K, 0603, .1W, 5% 199403-472
R235 820 OHM, 0603, .1W, 5% 199403-821
R236 820 OHM, 0603, .1W, 5% 199403-821
R237 100K, 0603, .1W, 5% 199403-104
R238 100K, 0603, .1W, 5% 199403-104
R239 1.0K, 0603, .1W, 1% 191465-1001
R240 1.0K, 0603, .1W, 1% 191465-1001
R241 1.0K, 0603, .1W, 1% 191465-1001
R242 10K, 0603, .1W, 5% 199403-103
R243 1.0K, 0603, .1W, 1% 191465-1001
R244 1.0K, 0603, .1W, 1% 191465-1001
R245 1.0K, 0603, .1W, 1% 191465-1001
R246 1.0K, 0603, .1W, 1% 191465-1001
R247 1.0K, 0603, .1W, 1% 191465-1001
R248 1.0K, 0603, .1W, 1% 191465-1001
R249 1.0K, 0603, .1W, 1% 191465-1001
R250 10K, 0603, .1W, 5% 199403-103
R251 2.2K, 0603, .1W, 5% 199403-222
R252 2.2K, 0603, .1W, 5% 199403-222
R253 10K, 0603, .1W, 5% 199403-103
R254 1.0K, 0603, .1W, 1% 191465-1001
R255 1.0K, 0603, .1W, 1% 191465-1001
R256 2.2K, 0603, .1W, 5% 199403-222
R257 10K, 0603, .1W, 1% 191465-1002
R258 10K, 0603, .1W, 1% 191465-1002
R259 10K, 0603, .1W, 5% 199403-103
R301 1.33K, 0603, 100mW, 1% 191465-1331
R302 1.33K, 0603, 100mW, 1% 191465-1331
R303 47K, 0603, .1W, 5% 199403-473
