56
Tuner PCB 260322-1
Electrical Part List
(Resistors)
Reference
Designator
Description Part Number Note
R101 1K, 0603, .1W, 5% 199403-102
R102 120 OHM, 0603, .1W, 5% 199403-121
R103 150 OHM, 0603, .1W, 5% 199403-151
R104 100K, 0603, .1W, 5% 199403-104
R105 47K, 0603, .1W, 5% 199403-473
R106 2.32K, 0603, .1W, 1% 191465-2321
R107 499 OHM, 0603, .1W, 1% 191465-4990
R108 3.01K, 0603, .1W, 1% 191465-3011
R109 2.32K, 0603, .1W, 1% 191465-2321
R110 330 OHM, 0603, .1W, 1% 191465-3300
R111 1.18K, 0603, 100MW, 1% 191465-1181
R112 22 OHM, 0603, .1W, 5% 199403-220
R113 4.75K, 0603, .1W, 1% 191465-4751
R114 100 OHM, 0603, .1W, 1% 191465-1000
R115 17.8K, 0603, 0.1W, 1% 191465-1782
R116 51 OHM, 0603, 100mW, 5% 199403-510
R117 2.32K, 0603, .1W, 1% 191465-2321
R118 3.01K, 0603, .1W, 1% 191465-3011
R119 5.1K, 0603, .1W, 5% 199403-512
R120 5.1K, 0603, .1W, 5% 199403-512
R121 51 OHM, 0603, 100mW, 5% 199403-510
R122 13K, 0603, .1W, 1% 191465-1302
R123 17.8K, 0603, .1W, 1% 191465-1782
R124 3.32K, 0603, .1W, 1% 191465-3321
R125 3.32K, 0603, .1W, 1% 191465-3321
R126 2.21K, 0603, .1W, 1% 191465-2211
R127 2.21K, 0603, .1W, 1% 191465-2211
R128 4.75K, 0603, .1W, 1% 191465-4751
R129 5.62K, 0603, 100mW, 1% 191465-5621
R130 5.62K, 0603, 100mW, 1% 191465-5621
R134 10K, 0603, .1W, 5% 199403-103
R135 10K, 0603, .1W, 5% 199403-103
R136 10K, 0603, .1W, 5% 199403-103
R137 51K, 0603, SMD, 100mW 199403-513
R138 51K, 0603, SMD, 100mW 199403-513
R139 1K, 0603, .1W, 5% 199403-102
R140 1K, 0603, .1W, 5% 199403-102
R141 1K, 0603, .1W, 5% 199403-102
R142 10K, 0603, .1W, 5% 199403-103
R145 100 OHM, 0603, .1W, 5% 199403-101
R146 4.75K, 0603, .1W, 1% 191465-4751
R148 20.0K, 0603, .1W, 1% 191465-2002
R149 51 OHM, 0603, 100mW, 5% 199403-510
R150 68.1K, 0603, .1W, 1% 191465-6812
R151 4.75K, 0603, .1W, 1% 191465-4751
R159 3.01K, 0603, .1W, 1% 191465-3011
R161 4.7K, 0603, .1W, 5% 199403-472
R163 4.7K, 0603, .1W, 5% 199403-472
R164 1 OHM, 0805, 1/10W, 5% 133626-1R05
R169 10K, 0603, .1W, 5% 199403-103
R201 4.7K, 0603, .1W, 5% 199403-472
R202 47 OHM, 0603, SMD, 100mW 199403-470
R203 470 OHM, 0603, 0.1W, 5% 199403-471
