57
Tuner PCB 260322-1
Electrical Part List
(Resistors continued)
Reference
Designator
Description Part Number Note
R204 430 OHM, 0603, SMD, 100mW 199403-431
R205 1K, 0603, .1W, 5% 199403-102
R206 68.1K, 0603, .1W, 1% 191465-6812
R207 6.81K, 0603, 0.1W, 1% 191465-6811
R208 9.1K, 0603, .1W, 5% 199403-912
R209 10K, 0603, .1W, 5% 199403-103
R210 100K, 0603, .1W, 5% 199403-104
R211 1M, 0603, .1W, 5% 199403-105
R212 4.7K, 0603, .1W, 5% 199403-472
R213 4.7K, 0603, .1W, 5% 199403-472
R214 5.62 OHM, 0603, 100mW, 1% 191465-5R62
R215 10K, 0603, .1W, 5% 199403-103
R216 1.5K, 0603, SMD, 100mW, 5% 199403-152
R217 3.48K, 0603, .1W, 1% 191465-3481
R218 620 OHM, 0603, .1W, 5% 199403-621
R301 33.2K, 0603, .1W, 1% 191465-3322
R302 13K, 0603, .1W, 1% 191465-1302
R304 10K, 0603, .1W, 1% 191465-1002
R305 3.74K, 0603, .1W, 1% 191465-3741
R306 2.21K, 0603, .1W, 1% 191465-2211
R307 3.32K, 0603, .1W, 1% 191465-3321
R308 200K, 0603, .1W, 1% 191465-2003
R309 100K, 0603, .1W, 5% 199403-104
R310 100K, 0603, .1W, 5% 199403-104
R311 3.32K, 0603, .1W, 1% 191465-3321
R312 2.21K, 0603, .1W, 1% 191465-2211
R313 200K, 0603, .1W, 1% 191465-2003
R314 100K, 0603, .1W, 5% 199403-104
R315 100K, 0603, .1W, 5% 199403-104
R316 51K, 0603, SMD, 100mW 199403-513
R317 10K, 0603, .1W, 5% 199403-103
R318 100K, 0603, .1W, 5% 199403-104
R319 1K, 0603, .1W, 5% 199403-102
R320 100K, 0603, .1W, 5% 199403-104
R321 1 OHM, 2010, 1/2W, 5% 187608-1R05
R322 1K, 0603, .1W, 5% 199403-102
(Capacitors)
Reference
Designator
Description Part Number Note
C102 10pF, 0805, COG, 50V, 5% 133622-100
C103 .047uF, 0805, X7R, 50V, 10% 133623-473
C105 .047uF, 0805, X7R, 50V, 10% 133623-473
C106 .047uF, 0805, X7R, 50V, 10% 133623-473
C107 9.1pF, 0603, COG, 50V 188454-9R1
C108 .047uF, 0805, X7R, 50V, 10% 133623-473
C111 2.2uF, EL, 85, 50V, 20% 149947-2R2H
C112 .047uF, 0805, X7R, 50V, 10% 133623-473
C113 .047uF, 0805, X7R, 50V, 10% 133623-473
C114 47uF, EL, 85, 16V, 20% 149947-470C
C115 .047uF, 0805, X7R, 50V, 10% 133623-473
To Next Page
