Bose AV28 User Manual

58
Tuner PCB 260322-1
Electrical Part List
(Capacitors continued)
Reference
Designator
Description Part Number Note
C116 .27uF, 1206, X7R, 16V, 10% 181998-274
C117 47uF, EL, 85, 25V, 20% 149947-470E
C118 1.0uF, EL, 85, 50V, 20% 149947-1R0H
C119 180pF, 0805, COG, 50V, 5% 133622-181
C120 1.0uF, EL, 85, 50V, 20% 149947-1R0H
C121 1.0uF, EL, 85, 50V, 20% 149947-1R0H
C122 .47uF, EL, 85, 50V, 20% 149947-R47H
C123 22uF, EL, 85, 25V, 20% 149947-220E
C124 560pF, 0603, X7R, 50V 191470-561
C125 47uF, EL, 85, 25V, 20% 149948-470E
C126 .01uF, 0603, X7R, 50V 191470-103
C127 10uF, EL, 85, 16V, 20% 149947-100C
C128 10uF, EL, 85, 16V, 20% 149947-100C
C129 10uF, EL, 85, 16V, 20% 149947-100C
C130 .047uF, 0805, X7R, 50V, 10% 133623-473
C131 3.3uF, EL, 85, 50V, 20% 149947-3R3H
C132 .047uF, 0805, X7R, 50V, 10% 133623-473
C133 .047uF, 0805, X7R, 50V, 10% 133623-473
C141 100pF, 0603, COG, 50V, 5% 188454-101
C142 33pF, 0603, COG, 50V, 5% 188454-330
C143 1000pF, 0603, X7R, 50V 191470-102
C144 33pF, 0603, COG, 50V, 5% 188454-330
C145 .047uF, 0805, X7R, 50V, 10% 133623-473
C146 .01uF, 0603, X7R, 50V 191470-103
C148 1000pF, 0603, X7R, 50V 191470-102
C149 100uF, EL, 85, 16V, 20% 149947-101C
C150 2.2uF, EL, BP, 85, 50V, 20% 147522-2R2
C151 .047uF, 0603, X7R, 5%, 25V 196999-473
C152 .047uF, 0805, X7R, 50V, 10% 133623-473
C201 68pF, 0603, COG, 50V, 5% 188454-680
C203 .01uF, 0603, X7R, 50V 191470-103
C204 68pF, 0603, COG, 50V, 5% 188454-680
C205 180pF, 0603, COG, 50V 188454-181
C206 .01uF, 0603, X7R, 50V 191470-103
C207 4700pF, 0603, X7R, 50V 191470-472
C208 4700pF, 0603, X7R, 50V 191470-472
C210 39pF, 0603, COG, 50V, 5% 188454-390
C211 1000pF, 0603, X7R, 50V 191470-102
C212 1000pF, 0603, X7R, 50V 191470-102
C213 .47uF, 1206, X7R, 16V, 10% 181998-474
C214 1000pF, 0603, X7R, 50V 191470-102
C216 390pF, 0603, COG, 50V 188454-391
C217 390pF, 0603, COG, 50V 188454-391
C218 33pF, 0603, COG, 50V, 5% 188454-330
C219 6.8pF, 0603, COG, 50V, 5% 188454-6R8
C220 1000pF, 0603, X7R, 50V 191470-102
C221 560pF, 0603, X7R, 50V 191470-561
C222 180pF, 0603, COG, 50V 188454-181
C223 1000pF, 0603, X7R, 50V 191470-102
C224 180pF, 0603, COG, 50V 188454-181
C301 390uF, EL, 85, 20%, 50V 258490-391B25H
C302 .047uF, 0805, X7R, 50V, 10% 133623-473
