Bose AV28 User Manual

59
Tuner PCB 260322-1
Electrical Part List
(Capacitors continued)
Reference
Designator
Description Part Number Note
C303 2200pF, 0603, X7R, 50V 191470-222
C304 .047uF, 0805, X7R, 50V, 10% 133623-473
C305 0.10uF, 0603, 16V, 5% 258498-104
C306 0.47uF, 1812, X7R, 50V, 20% 258418-4743
C307 470pF, 0603, X7R, 50V 191470-471
C308 0.47uF, 1812, X7R, 50V, 20% 258418-4743
C310 1000uF, EL, 105, 20%, 25V 258490-102B25E
C312 0.1uF, 0805, X7R, 50V, 10% 133624
C313 10uF, EL, 85, 16V, 20% 149947-100C
C314 .047uF, 0805, X7R, 50V, 10% 133623-473
C315 .047uF, 0805, X7R, 50V, 10% 133623-473
C316 .047uF, 0805, X7R, 50V, 10% 133623-473
C317 .047uF, 0805, X7R, 50V, 10% 133623-473
C319 .33uF, BOX, 85, 50V, 5% 137127-334
C320 330pF, 0603, COG, 50V, 5% 188454-331
C321 1000pF, X7R, 50V, 0603, 5% 260345-102
C322 470pF, 0603, COG, 50V, 5% 188454-471
C323 10uF, EL, 85, 16V, 20% 149947-100C
C324 .022uF, 0603, X7R, 25V 196999-223
C325 0.056uF, 0603, 16V, 5% 258498-563
C326 150pF, 0603, COG, 50V, 5% 188454-151
C327 1800pF, 0603, X7R, 50V, 10% 191470-182
C328 1000pF, X7R, 50V, 0603, 5% 260345-102
(Diodes)
Reference
Designator
Description Part Number Note
D202 SOT, MMBD914LT1 148582
D203 BAV99, SOT23 147239
D301 SCHOTTKY, 40V, 3A, SMB 193847-001
D302 SOT-23, BAV70 147249
D303 SOT-23, BAV70 147249
(Transistors)
Reference
Designator
Description Part Number Note
Q101 PNP, SOT, 47K 146818
Q102 BPLR, N, 25V, 30mA, SOT-23 187601-001
Q103 JFET, N, 20V, 20mA, TO-92 148590-E
Q201 PNP, SOT, 47K 146818
Q202 NPN, SOT, 2SC2814 148781-4
Q203 NPN, SOT, 47K 146817
Q204 PNP, SOT, MMBT3906 148596
Q205 NPN, 1.3W, SOT-223 258416-001
Q206 NPN, SOT, 47K 146817
Q207 NPN, SOT, MMBT3904 146819
Q208 JFET, N, 40V, 10mA, TO-92 147561-3
Q209 NPN, SOT, 47K 146817
