60
Tuner PCB 260322-1
Electrical Part List
(Integrated Circuits)
Reference
Designator
Description Part Number Note
U101 AM/FM TUNER, MFP-30S 254561-001
U103 PLL FREQSYNTH, LC72144M 260347-001
U104 DUALCOMPARITOR, SO-8, LM393 148584
U301 VOLT REG, 3.3V, 3.5A, SMPS 193846-001
U302 VOLT, REG, 10V, POS 178352-10
U303 OPAMP, QUAD, NJM3403AM 194024
(Miscellaneous)
Reference
Designator
Description Part Number Note
CF101 FILTER, CER, BAND PASS, FGD 253037-002
CF102 FILTER, CER, BAND PASS, FGD 253037-001
FB1 BEAD, FERRITE, CHIP, 1806 256116-181 3
FM-TNR101 TUNER, FM, 258513-001
J101 CONN, AM ANTENNA, 2.5MM 179266
J102 CONNNECTOR, FM, SHIELDED, US 258434-001
J103 CONN, HEADER, 30P, TOP-ENTRY, SMT 253356-T30
J104 CONN, DC POWER JACK 256763-001 3
J105 CONN, SERIAL 178356
L101 1000uH, AX ON ALR, 40A 260363-102
L201 10uH, SMT, LEM4532 178370-100
L202 100nH, 0603, 5% 191488-101J
L203 1.0uH, SMD, 20% 173273-1R0
L204 220nH, 0805, 5% 191469-221J
L205 1.0uH, SMD, 20% 173273-1R0
L301 100uH 131297
L302 330uH, SMD, 20% 178336-331J
L303 330uH, SMD, 20% 178336-331J
L304 22uH, COMMON MODE 187598-220
RR201 RECEIVER, RF REMOTE, 27.145MHZ 258376-001
RT1 LIMITER, CURRENT, 2.5A 258500-001
SHLD-TNR SHIELD, FENCE 256743
T101 MODULE, TUNING, AM, FRONT END 195359
T102 FILTER, AM-IF, QUINTIPLE TUNED 254114-001
T103 COIL, FM DISCRIMINATOR 254564-001
T104 FILTER, STEREO MPX, SINGLE TUNED 147236
T105 FILTER, STEREO MPX, SINGLE TUNED 147236
Y102 CRYSTAL, QUARTZ, 7.2MHz, 50PPM 147223
Y201 CRYSTAL, 27.145MHZ, FUNDAMENTAL 260353-001
