Bose AV28 User Manual

55
(Miscellaneous)
Main PCB 260318-0
Electrical Part List
Reference
Designator
Description Part Number Note
CR701 RESNTR, CER, W/INTGRTD CAPS, 8
MHZ
191446-8R00
FB301 400 OHM, CHIP, 0805 188587-401
FB401 400 OHM, CHIP, 0805 188587-401
FB701 BEAD, FERRITE, CHIP, 1806 256116-181 3
FB702 BEAD, FERRITE, CHIP, 1806 256116-181 3
J1000 CONNECTOR, HEADER, RTANG, EH 256114-04
J101 CONN, HEADER, 30P, TOP-ENTRY, SMT 253356-T30
J102 CONN, HEADER, 10 POS 148591-10
J103 CONN, HEADER, 5 POS 148591-05
J104 CONNECTOR, HEADER, 40 PIN 256105-001
J106 CONN, HEADER, 4 POS 148591-04
J201 CONNECTOR, RCA STACK 256106-001 OR 256106-002
J213 CONN, HEADER, 4 POS 148591-04
J301 CONN, DUAL, DIN, 8 POS 178355
J501 CONNECTOR, OPTICAL, JF J2001 258421-001
J601 CONN, DIN, DUAL, 4 POS, W/FLANGE 256107-002
J701 CONNECTOR, OPTICAL, JF J1000 258420-001
J704 CONNECTOR, JACK, DUAL, STEREO 268897-001
J2000 CONN, JACK, HEAD PHONE, PCB MNT,
9P
148583
J2001 CONNECTOR, HEADER, RTANG, EH 256114-04
L100 22uH, COMMON MODE 187598-220
L2000 100uH, SMT, LEM4532 178370-101
L2001 100uH, SMT, LEM4532 178370-101
L602 1.8uH, CERAMIC 1812, 5% 263452-1R8J
L603 1.8uH, CERAMIC 1812, 5% 263452-1R8J
L604 1.8uH, CERAMIC 1812, 5% 263452-1R8J
L605 10uH, SMT, LEM4532 178370-100
L802 100uH 131297
L804 90 OHM 196676
T301 TRANSFORMER, PULSE 254185-001
T401 TRANSFORMER, PULSE 254185-001
T701 TRANSFORMER, PULSE 254185-001
Y301 CRYSTAL, 11.2896 MHZ, HC49S, SMD 197225
Y700 XTAL, 27MHZ, +/-50PPM, HC-49U 256102-002

Bose AV28 Specifications

General

Type	DVD player
Progressive Scan	Yes
Remote Control	Yes
Upscaling	No
Playable Media Format	DVD, CD, MP3
Video Output	Component, Composite, S-Video
Audio Output	Digital Optical, Digital Coaxial
